Specifications
Brand Name :
Anycut
Model Number :
ZKD1500-SF
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
MOQ :
1piece
Price :
$1070~1398/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L1810mm*W400mm*H440mm
Max.cutting width :
1250mm
Control panel :
5.0 inch LCD touch screen
Motor :
Servo motor
Cutting length :
Unlimited
Max.cutting speed :
1200mm/s
Max. force :
2000g
Main board :
ARM smart dual-core chip
Auto contour cutting :
camera
connect or interface :
USB cable/Udisk/WIFI(optional)/Web cable(optional)
support software :
CDR/AI/PS/Contour software/signmaster(optional)
Description

Dual -head Cutting Trolley 1200mm/s Multi-functional Cutting Plotter CCD Camera Positioning



Equipped with a high-speed servo motor, the ZKD1550-SF delivers a maximum cutting speed of 1200mm/s, ensuring efficient and precise production.

Boasting a 2000g super force and ±0.01mm cutting accuracy, this machine handles a wide range of materials—from reflective film and advertising vinyl to hollow boards and photo paper—with consistent, repeatable precision. The built-in camera automatic positioning function guarantees accurate contour cutting, eliminating manual alignment errors.

Powered by an ARM smart dual-core chip and compatible with all Windows versions, it integrates effortlessly into your existing production setup. Whether you're processing large-format media up to 1500mm wide or intricate details, the ZKD1500-SF is engineered to elevate your cutting performance.



MODEL ZKD1550-SF
Max. media width 1550mm
Max. cutting width 1250mm
Packing size L 1810mm*W 400mm*H 440mm
Machine size L 1700mm*W 600mm*H 1100mm
Gross/Net weight 50kgs/42kgs
Control panel 5.0inch LCD touch screen
Motor Servo motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 1200mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 2
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/WIFI(optional)/Web cable(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows
