Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
Specifications
Brand Name :
Anycut
Model Number :
ZKD1550-SF
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
MOQ :
1piece
Price :
$1070~1398/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L1810mm*W400mm*H440mm
Max.cutting width :
1250mm
Control panel :
5.0 inch LCD touch screen
Motor :
Servo motor
Cutting length :
Unlimited
Max.cutting speed :
1200mm/s
Max. force :
2000g
Main board :
ARM smart dual-core chip
Auto contour cut :
camera
connect or interface :
USB cable/Udisk/WIFI(optional)/Web cable(optional)
support software :
CDR/AI/PS/Contour software/signmaster(optional)
Description

Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning



The ZKD1550-SF is a high-performance cutting plotter powered by a high-speed servo motor, designed to handle large-format cutting tasks with exceptional precision and efficiency. It features a dual-knife head carriage, 2000g of cutting force, and camera automatic positioning, making it ideal for sign shops, advertising agencies, and print businesses that demand reliability and versatility.

-Dual Knife Head System:

Supports full cut, half cut, creasing, and kiss-cut operations in one pass, maximizing productivity for jobs like reflective film, hollow-out boards, and advertising materials.


- Camera Auto-Contour Cutting:

Automatically detects printed contours for precise alignment, eliminating manual positioning errors and ensuring perfect results every time.


- Fast & Accurate Performance:

Delivers a maximum cutting speed of 1200mm/s with ±0.01mm cutting accuracy, and a repeatability of 0.08mm, ensuring both speed and precision.
With a maximum media width of 1500mm and a cutting width of 1200mm.



MODEL ZKD1550-SF
Max. media width 1550mm
Max. cutting width 1250mm
Packing size L1810mm*W400mm*H440mm
Machine size L1700mm*W600mm*H1100mm
Gross/Net weight 50kgs/42kgs
Control panel 5.0inch LCD touch screen
Motor Servo motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 1200mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 2
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/WIFI(optional)/Web cable(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows



Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning



Large Format Servo Motor Full Cut And Half Cut Cutting Machine With Camera Automatic Positioning
