Specifications
Brand Name :
Anycut
Model Number :
ZK1400-SF
MOQ :
1 piece
Price :
$670~999/piece
Payment Terms :
T/T,Western Union
Certification :
CE/FCC/RoHS
Place of Origin :
Shenzhen
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L1650mm*W600mm*H1100mm
Max.cutting width :
1250mm
Control panel :
5.0 inch touch screen
Motor :
Servo drive+Servo motor
Cutting length :
unlimited
Max.cutting speed :
1200mm/s
Max.force :
2000g
Main board :
ARM smart dual-core chip
Auto contour cut :
Camera
Description

Anycut 55 Inch Servo Smart Cutting Plotter Camera Auto-positioning High Speed Precision Cutting



The ZK1400-SF is an intelligent cutting tool tailored for complex material processing, boasting three core upgraded advantages: precision, efficiency, and flexibility. Equipped with a high-definition CCD camera, it captures details clearly even on reflective materials. Its built-in suction-assisted paper feeding design eliminates material shifting and wrinkling, ensuring stability during high-speed cutting. With a 1200mm/s cutting speed and 2000g high pressure.

What makes it more user-friendly is its layout flexibility: free switching between irregular and set-based layouts, plus customizable marker points (color, distance, shape). During batch processing, it adapts to irregular materials while supporting one-click standardized production. The built-in servo motor enables ultra-quiet operation; dual WiFi/wired network connectivity frees users from cable constraints; From reflective signs to irregular stickers, from batch cardstock to film processing, it meets personalized needs across scenarios with "visible precision, controllable flexibility, and quiet efficiency."



MODEL ZK1400-SF
Max. media width 1400mm
Max. cutting width 1250mm
Packing size L1760mm*W400mm*H440mm
Machine size L1650mm*W600mm*H1100mm
Gross/Net weight 42kgs/36kgs
Control panel 5.0inch LCD touch screen
Motor Servo drive + Servo motor
Cutting length Unlimited
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.cutting speed 1200mm/s
Max.force 2000g
Main board ARM smart dual-core chip
Auto contour cut Camera
Number of heads 1
Number of Y motor 1
Blade type Rowland blade
Floorstand yes
Drawing instruction Automatic recognition DMPI and HPGL
Connect or interface USB cable/Udisk/web cable/WIFI(optional)
Power ﹤100w
Working environment ﹢5℃﹣﹢35℃
Power supply 100v-240v(adaptive),50HZ/60HZ
Support software CDR/AI/PS/Contour software/signmaster(optional)
Memory 1G
Support system All versions of windows
