1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
1000W Affordable Hobby Fiber Laser Cutting Machine
Specifications
Technical Class :
Continuous Wave Laser
Transport Package :
Wooden Pallet
Model NO. :
HBS-LCT600
Specification :
1400*1700*1760mm
Laser Classification :
Solid Laser
Laser Power :
500W/800W/1000W/1500W
Weight of Basic Machine :
1200kg
Laser Brands :
Feibo / Raycus / Ipg
Working Area :
600*600mm
Power Consumption :
7kw/6.5kw/6kw/5.5kw
Laser Source :
Fiber
CNC or Not :
Yes (Japanese Linear Motor)
Repetitive Positioning Accuracy :
0.005mm
HS Code :
84561000
Laser Technology :
Laser Vapor Cutting
Positioning Accuracy :
0.02mm
MOQ :
1 Set
Applicable Material :
Metal
Structure Type :
Gantry Type
Origin :
China
Max. Cutting Speed :
30m/Min
Trademark :
HBS
Price :
US $50,000-90,000
Production Capacity :
100PCS/Year
Description
Overview

1000W Affordable Hobby Fiber Laser Cutting Machine is specially designed for cutting small parts in both lab testing and industrial environments. Using high-speed linear motors with marble platform gives our laser cutter the stability and acceleration needed for high-speed precision cutting. Utilizing the world top class fiber laser source, our laser cutting machine can ensure you of the best quality. Working on a variety of materials including steel, aluminum, brass, copper, titanium and alloys, our laser cutting machine provides extraordinary cutting performance and reliability.

Features
  • Fiber Laser High Efficiency and Low Operating Costs
  • Highly Stable Granite Structure
  • High-Speed Linear Motor for Faster Cutting Speed and High Precision
  • Compact Design to Reduce Facility Cost
  • Wide Range of Laser Power Selection to Reduce Your Purchasing Cost
  • Fully Enclosed System Meet CE & FDA Standards
  • Auto Stop Protection: When Cutting Head Detect Collision Between the Cutting Head and the Tilted Parts
  • Available Assist Gases for Cutting Different Materials
Specifications
Laser Brands Feibo / Raycus / IPG
Laser Source Fiber
Laser Wavelength 1064nm
Laser Power 500W/800W/1000W/1500W
Max. Cutting Speed 30m/min
CNC or not Yes (Japanese Linear Motor)
Working Area 500*500mm
Power Supply Single-Phase 220V / 3-Phase 380V (Depending on the laser source)
Positioning Accuracy ±0.02mm
Repetitive Positioning Accuracy ±0.005mm
Power Consumption 7kw/6.5kw/6kw/5.5kw
Cooling Method Water Cooling
Weight of Basic Machine 1200KG
Machine Dimension(L*W*H) 1400*1700*1760mm
Assist Gases Oxygen, Nitrogen, Compressed Air
Processable Materials Stainless steel, Carbon steel, Mild steel, Alloy steel, Silicon steel, Spring steel, Aluminum, Aluminum alloy, Galvanized sheet metal, Aluminum-zinc coated sheet metal, pickling metal, Copper, Brass, Silver, Gold, Titanium and other metals.
After-sales Service Provided Engineers available to service machinery overseas
