Specifications
Technical Class :
Continuous Wave Laser
Transport Package :
Wooden Pallet
Model NO. :
HBS-LCT600
Specification :
1400*1700*1760mm
MOQ :
1 Set
Price :
US $50,000-90,000
Laser Classification :
Solid Laser
Laser Power :
500W/800W/1000W/1500W
Weight of Basic Machine :
1200kg
Laser Brands :
Feibo / Raycus / Ipg
Working Area :
600*600mm
Power Consumption :
7kw/6.5kw/6kw/5.5kw
Laser Source :
Fiber
CNC or Not :
Yes (Japanese Linear Motor)
Laser Technology :
Laser Vapor Cutting
Positioning Accuracy :
0.02mm
Trademark :
HBS
Repetitive Positioning Accuracy :
0.005mm
HS Code :
84561000
Applicable Material :
Metal
Structure Type :
Gantry Type
Origin :
China
Max. Cutting Speed :
30m/Min
Production Capacity :
100PCS/Year
Description
Overview

1000W Laser Cutting System / Laser Cutting Machine is specially designed for cutting small parts in both lab testing and industrial environments. Using high-speed linear motors with marble platform gives our laser cutter the stability and acceleration needed for high-speed precision cutting. Utilizing the world top class fiber laser source, our laser cutting machine can ensure you of the best quality. Working on a variety of materials including steel, aluminum, brass, copper, titanium and alloys, our laser cutting machine provides extraordinary cutting performance and reliability.

Features
  • Fiber Laser High Efficiency and Low Operating Costs
  • Highly Stable Granite Structure
  • High-Speed Linear Motor for Faster Cutting Speed and High Precision
  • Compact Design to Reduce Facility Cost
  • Wide Range of Laser Power Selection to Reduce Your Purchasing Cost
  • Fully Enclosed System Meet CE & FDA Standards
  • Auto Stop Protection: When Cutting Head Detect Collision Between the Cutting Head and the Tilted Parts
  • Available Assist Gases for Cutting Different Materials
Specifications
Laser Brands Feibo / Raycus / IPG
Laser Source Fiber
Laser Wavelength 1064nm
Laser Power 500W/800W/1000W/1500W
Max. Cutting Speed 30m/min
CNC or not Yes (Japanese Linear Motor)
Working Area 500*500mm
Power Supply Single-Phase 220V / 3-Phase 380V (Depending on the laser source)
Positioning Accuracy ±0.02mm
Repetitive Positioning Accuracy ±0.005mm
Power Consumption 7kw/6.5kw/6kw/5.5kw
Cooling Method Water Cooling
Weight of Basic Machine 1200KG
Machine Dimension(L*W*H) 1400*1700*1760mm
Assist Gases Oxygen, Nitrogen, Compressed Air
Processable Materials Stainless steel, Carbon steel, Mild steel, Alloy steel, Silicon steel, Spring steel, Aluminum, Aluminum alloy, Galvanized sheet metal, Aluminum-zinc coated sheet metal, pickling metal, Copper, Brass, Silver, Gold, Titanium and other metals.
After-sales Service Provided Engineers available to service machinery overseas
