Specifications
Brand Name :
HAIDA
Place of Origin :
Guangdong, China
MOQ :
1
Accuracy :
0.01℃
Power :
5.5kw
Voltage :
380 V
Capacity :
60L/100L/150L/408L/800L/1000L
Internal dimension :
400*500*500 mm
External dimension :
700*1400*1100mm
Temperature range :
-70℃~+150℃
Temperature fluctuation :
±0.5℃
Temperature accuracy :
0.01℃
Humidity range :
20~98%RH
Humidity accuracy :
0.1%RH
Cooling speed :
1℃/min
Heating speed :
3℃/min
Internal material :
SUS#304 stainless steel
External material :
Stainless steel
Description
Environmental Climate Chamber - Constant Environment Stability Temperature and Humidity Controlled Test Chamber
Model: HD-E702
Professional temperature and humidity test chamber designed to evaluate material performance under various environmental conditions. Tests heat resistance, cold resistance, dry resistance, and humidity resistance of diverse materials.
Environmental Climate Chamber Haida Constant Environment Stability Temperature and Humidity Controlled Test Chamber Environmental Climate Chamber Haida Constant Environment Stability Temperature and Humidity Controlled Test Chamber
Applications
Ideal for quality testing of electronics, electrical appliances, mobile phones, communications equipment, instruments, vehicles, plastic products, metals, food, chemicals, building materials, medical devices, aerospace components, and more.
Technical Specifications
Model Dimensions
Model Internal Dimension (W×H×D) External Dimension (W×H×D)
HD-E702-100 400×500×500mm 700×1400×1100mm
HD-E702-150 500×500×600mm 800×1500×1100mm
HD-E702-225 500×750×600mm 800×1670×1200mm
HD-E702-408 600×850×800mm 900×1770×1400mm
HD-E702-1000 1000×1000×800mm 1550×2100×1400mm
Performance Specifications
Internal dimension (W×D×H) 400×500×500mm
External dimension (W×D×H) 700×1400×1100mm
Temperature range -20℃, -40℃, -60℃, -70℃ to +150℃
Temperature fluctuation ±0.5℃
Temperature uniformity ≤1.5℃
Humidity range 20~98%RH
Humidity fluctuation ≤±2.5%RH
Humidity uniformity 3%RH
Cooling speed 1℃/min average (without loading)
Heating speed 3℃/min average (without loading)
Construction & Components
Internal chamber material SUS#304 stainless steel, mirror finished
External chamber material Stainless steel
Cooling method Air cooling
Controller LCD touch screen, programmable control temperature and humidity
Insulation material 50mm high density rigid Polyurethane foam
Heater Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
Compressor France Tecumseh compressor × 2 sets
Lighting Heat resistance
Temperature sensor PT-100 dry and wet bulb sensor
Observation window Tempered glass
Testing hole Diameter 50mm, for cable routing
Sample tray SUS#304 stainless steel, 2pcs
Safety Protection Systems
  • Protection for leakage
  • Over-temperature protection
  • Compressor overvoltage and overload protection
  • Heater short circuit protection
  • Water shortage protection
Chamber Applications
  • Simulate test environments with different temperature and humidity conditions
  • Cyclic testing including climatic conditions: holding test, cooling-off test, heating-up test, moistening test and drying test
  • Cable port with flexible silicone plug for cable routing to provide conditions for test units under operation
  • Uncover test unit weaknesses in short-term tests with accelerated time effect
Design Features
  • High performance and quiet operation (68 dBA)
  • Space-saving design for flush installation to wall
  • Full thermal break around door-frame
  • One 50mm diameter cable port on left, with flexible silicone plug
  • Accurate wet/dry-bulb humidity measurement system for easy maintenance
Programmable Controller
  • PLC controller for test chamber
  • Step types include: ramp, soak, jump, auto-start, and end
  • RS-232 interface to connect computer for output
