Specifications
Brand Name :
Huawei
Model Number :
UBBP
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
15 working days
Description
Table 1 Modes supported by UBBP boards

Board

Single Mode

Multimodea
UBBPd1 GSM/UMTS GU co-BBP
UBBPd2 GSM/UMTS GU co-BBP
UBBPd3 GSM/UMTS/LTE FDD/LTE NB-IoT GU co-BBP/GL co-BBP/LM co-BBP
UBBPd4 GSM/UMTS/LTE FDD/LTE NB-IoT/LTE TDD GU co-BBP/GL co-BBP/LM co-BBP
UBBPd5 GSM/UMTS/LTE FDD/LTE NB-IoT GU co-BBP/GL co-BBP/LM co-BBP
UBBPd6 GSM/UMTS/LTE FDD/LTE NB-IoT/LTE TDD GU co-BBP/GL co-BBP/UL co-BBP/LM co-BBP/UM co-BBP/LT co-BBP/GUL co-BBP/ULM co-BBP/LTM co-BBP
UBBPd9 LTE TDD -
UBBPe1 UMTS/LTE FDD/LTE NB-IoT LM co-BBP
UBBPe2 UMTS/LTE FDD/LTE NB-IoT LM co-BBP
UBBPe3 UMTS/LTE FDD/LTE NB-IoT UL co-BBP/LM co-BBP/UM co-BBP/ULM co-BBP
UBBPe4/UBBPe6 UMTS/LTE FDD/LTE NB-IoT/LTE TDD UL co-BBP/LM co-BBP/UM co-BBP/LT co-BBP/ULM co-BBP/TM co-BBP/LTM co-BBP

UBBPe5

 UMTS/LTE FDD/LTE NB-IoT UL co-BBP/LM co-BBP/UM co-BBP/LT co-BBP/ULM co-BBP/LTM co-BBP
UBBPe18 UMTS/LTE FDD/LTE NB-IoT/LTE TDD UL co-BBP/LM co-BBP/UM co-BBP/LT co-BBP/ULM co-BBP/TM co-BBP/LTM co-BBP
UBBPex2 LTE FDD -
UBBPem LTE TDD -
UBBPf1 LTE TDD -
UBBPf3 LTE TDD -
UBBPg1 UMTS/LTE FDD/LTE NB-IoT/LTE TDD/NR FDD UL co-BBP/LM co-BBP/UM co-BBP/LT co-BBP/ULM co-BBP/TM co-BBP/LTM co-BBP
UBBPg1a UMTS/LTE FDD/LTE NB-IoT/LTE TDD/NR FDD UL co-BBP/LM co-BBP/UM co-BBP/ULM co-BBP/LT co-BBP/TM co-BBP/LTM co-BBP/LN (FDD) co-BBP/LMN (FDD) co-BBP
UBBPg2 UMTS/LTE FDD/LTE NB-IoT/LTE TDD/NR FDD UL co-BBP/UM co-BBP/LM co-BBP/LT co-BBP/TM co-BBP/ULM co-BBP/LTM co-BBP/LN (FDD) co-BBP/LMN (FDD) co-BBP
UBBPg2a UMTS/LTE FDD/LTE TDD/LTE NB-IoT/NR TDD/NR FDD UL co-BBP/UM co-BBP/LM co-BBP/LT co-BBP/TM co-BBP/ULM co-BBP/LTM co-BBP/LN (FDD) co-BBP/LMN (FDD) co-BBP/TN (FDD) co-BBP/TN (TDD) co-BBP/LN (TDD) co-BBP/LMN (TDD) co-BBP
UBBPg3b UMTS/LTE FDD/LTE TDD/LTE NB-IoT/NR TDD/NR FDD UL co-BBP/UM co-BBP/LM co-BBP/LT co-BBP/TM co-BBP/ULM co-BBP/LTM co-BBP/TN (TDD) co-BBP/LN (TDD) co-BBP/LMN (TDD) co-BBP/LN (FDD) co-BBP/LMN (FDD) co-BBP/TN (FDD) co-BBP/LN (TDD) co-BBP/LMN (TDD) co-BBP
UBBPg3 UMTS/LTE FDD/LTE TDD/LTE NB-IoT/NR TDD/NR FDD UL co-BBP/UM co-BBP/LM co-BBP/LT co-BBP/TM co-BBP/ULM co-BBP/LTM co-BBP/TN co-BBP/TN (TDD) co-BBP/LN (FDD) co-BBP/LMN (FDD) co-BBP/LN (TDD) co-BBP/LMN (TDD) co-BBP/LN (FDD) N (TDD) co-BBP/LMN (FDD) N (TDD) co-BBP/N (FDD) N (TDD) co-BBP
UBBPg4 LTE TDD -
a: "G" is short for GSM, "U" for UMTS, "L" for LTE FDD, "T" for LTE TDD, "M" for LTE NB-IoT, and "N" for NR. In addition, "N (FDD)" is short for NR FDD and "N (TDD)" is short for NR TDD.
