High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
High Tensile Strengths Galvanised Overhead Ground Wire For Crane Beams
Specifications
Place of Origin :
Anhui,China
Brand Name :
Litong Global
Certification :
ISO9001 &Other 3rd Party Inspection
Model Number :
LT-15110101
MOQ :
Negotiable
Price :
Negotiable
Packaging Details :
On drum or In Coil
Delivery Time :
10days after confirmed order
Payment Terms :
TT/LC
Supply Ability :
400tons/Day
Steel Grade :
High Carbon Wire Rod
Wire Gauge :
1.57-4.8mm
Type :
Galvanized
Alloy Or Not :
Non-alloy
Special Use :
Free Cutting Steel
Application :
Guy Wire,Stay Wire,ACSR
Standard :
AISI|ASTM|BS|DIN|GB|JIS
Description

Description
Our galvanized stranded wires provide a combination of superior properties compared to conventional six strand ropes. With compacted structure and smooth face, this 1*7 galvanized stranded wire provides enhanced durability and resistance to abrasion and crushing, and improves the service life.
Construction & Diameter: 1*7/4.8-12.7 mm
Features
1. The galvanized stranded wire offers a smooth and polished surface.
2. It offers excellent antirust performance.
3. It is adhesive and flexible.
Application
Our 1*7 galvanized stranded wire can be used as messenger wires, guy wires, core wires or strength members, earth wires/ground wires, barrier cables, structure cables, messenger wires for optical fiber cable, etc.
As a professional 1*7 galvanized stranded wire manufacturer and supplier based in China, We also offers1*3, 1*19 galvanized stranded wire, 12.70mm PC strand, 2.0mm and 2.64mm galvanized steel wire, among others.

Grade

Dia.

(mm)

Tensile Strength

Not less

(Mpa)

Stress at elongation of 1%

Not less

(Mpa)

Elongation

L0=250mm

Not less

Torsion

Not less

Times/360°

Mandrel

Dia

≥1.24-2.25134011703.0161

Normal

≥2.25-2.75131011403.0161
≥2.75-3.00131011403.5161
≥3.00-3.50129011003.5141
≥3.5-4.25129011004.0121
≥4.25-4.75129011004.0121
≥4.75-5.5129011004.0121

High

≥1.24-2.25145013102.5161
≥2.25-2.75141012802.5161
≥2.75-3.00141012803.0161
≥3.00-3.50141012803.0141
≥3.5-4.25138012403.0121
≥4.25-4.75138011703.0121
≥4.75-5.5138011703.0121

Extra-

High

≥1.24-2.25162014502.0141
≥2.25-2.75159014102.0141
≥2.75-3.00159014102.5121
≥3.00-3.50155013802.5121
≥3.5-4.25152013402.5101
≥4.25-4.75152013402.5101
≥4.75-5.5152012702.5101

Contact us:
