Specifications
Brand Name :
CLINGSEAL
Model Number :
CSG80
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500kg
Price :
2.2USD PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500Tons per month
Delivery Time :
20 days
Packaging Details :
pallet/wooden case
Grade :
Industrial Grade
Type :
Flexible Sheet
Application :
gaskets
C content (%) :
99.9%
Thickness :
Customers' Demand
Material :
Graphite,High pure graphite
Industry Application :
Oil & Gas, Chemical, Power
Machinability :
Ease of Cutting/Shaping
Customization :
Tailored Dimensions/Shapes
Description

Online Custom Graphite Gasket Service

Products Description

Instant Custom Graphite Gasket Solutions

Our online platform offers tailor-made graphite-based sealing solutions including: flexible sheets, foils, papers, tapes, and strips. These materials are produced by intercalating natural graphite flakes with chemical agents, followed by thermal expansion to create worm-like structures (density ≈0.003g/cm³). The binder-free expanded graphite is then rolled into coils, delivering:

  • 99%+ purity
  • Corrosion/radiation resistance
  • Extreme temperature stability (-200°C to +650°C)
  • Compression recovery up to 40%
  • Self-lubricating performance
  • Gas-tight sealing

Online Customization Features:

  1. Real-time design quoting system
  2. CAD file upload for precision cutting
  3. Material selection wizard (pure/graphite-metal composite)
  4. Thickness calculator (0.15-5.0mm)

Industrial Applications:

  • Pump/valve sealing systems
  • High-temperature insulation components
  • Custom-shaped gaskets for energy sector
  • Automotive engine seals

Service Advantages:

  • 24/7 online ordering portal
  • Rapid prototyping (48-hour turnaround)
  • Free design optimization
  • Bulk pricing discounts

Standard Product Parameters:

  • Roll Width: 1000mm / 1500mm (custom widths available)
  • Coil Length: 30m / 50m / 80m (cut-to-size service)
  • Sheet Size: 1000x1000mm / 1500x1500mm
  • Density Range: 0.8-1.25g/cm³
  • Finish Options: Smooth / Textured / Metal-clad
Item Standard Value
C concentration 99%
S concentration <1000ppm
chlorine concentration <45ppm
tensile strength 4.5MPa
compressibility >40%
recovery >10%
Temperature -200ºC-600ºC
Pressure 20MPa
Terence of Thickness -0.04mm~+0.04mm
Terence of Dimension In accordance with your Gasket size
Terence of Density -0.06~g/cm3+0.06gcm3

Grades Separate :JB/T53392-1999
Mechanical Data Qualified product Top Grade Superior Grade
Density Tolerance
g/cm3
<0.4 ±0.10
±0.05
0.4 ±0.07
Tensile Strength MPa 3.2 4.5 5.0
Compression Ratio % 35~55
Rebound Rate % 9 11 12
Stress relaxation rate % 10
Ash % 6.0 3.0 1.0
Heat loss on ignation % 450ºC 1.0 0.5
600ºC 20 15

Sulphur content
1500ppm 1000ppm 600ppm

Chloride content
100ppm 50ppm 20ppm
