Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Sealing Expanded Graphite Sheet 99.9% Purity Aging Resistant
Specifications
Brand Name :
CLINGSEAL
Model Number :
CSG80
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500kg
Price :
2.2USD PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500Tons per month
Delivery Time :
20 days
Packaging Details :
pallet/wooden case
Grade :
Industrial Grade
Type :
Flexible Sheet
Application :
gaskets
C content (%) :
99.9%
Thickness :
Customers' Demand
Material :
Graphite,High pure graphite
Recyclability :
Environmentally Friendly
Dimensional Stability :
Low Thermal Expansion
Aging Resistance :
Long - Term Durability
Description

Products Description

Express Delivery Graphite Sealing Solutions

Advanced Material Production

Our expanded graphite materials—including flexible sheets, foil, paper, tape, and strips—are manufactured using a proprietary exfoliation process. Natural graphite flakes undergo chemical intercalation and high - temperature expansion (forming worm - like structures with 0.003g/cc density), then are rolled into binder - free coils. This vertically integrated production chain ensures consistent quality and rapid order fulfillment.

Fast Fulfillment Capabilities

  1. Automated Manufacturing
    • 24/7 operation of CNC rolling mills producing 800+ meters of coils daily
    • Laser cutting systems processing 1500+ gasket shapes per hour
  2. Global Inventory Network
    • 10,000+ m² warehouse with 500+ tons of stock in:
      • China (main facility)
      • Rotterdam (EU distribution hub)
      • Houston (US inventory center)
  3. Expedited Logistics
    • DHL/FedEx partnerships for 3 - 5 day delivery to 90+ countries
    • Customized packaging for air/sea/rail transport

Core Product Features

  • Purity: 99.8%+ carbon content (ICP - AES tested)
  • Temperature Range: - 200°C to +1600°C
  • Density Options: 0.8–1.25g/cm³ (stocked in 0.1g/cm³ increments)

Standard & Custom Specifications

  • Stock Sizes:
    • Coils: 1000mm/1500mm width, 30m/50m/80m length
    • Sheets: 1000mm x 1500mm, thicknesses 0.15mm–5mm
  • Customization:
    • Non - standard sizes available within 48 hours
    • Composite materials (graphite + metal/PTFE) ready in 7 days

Quality Assurance

  • ISO 9001:2015 certified production
  • In - line testing for:
    • Compressive strength (ASTM F36)
    • Thermal conductivity (ASTM C518)
    • Gas tightness (ASTM F137)

Case Study: Emergency Order Success

A German chemical plant received 12,000 custom - cut gaskets within 72 hours via our Rotterdam hub, avoiding $2M in downtime costs.

Why Choose Our Express Service?

  • Speed: Average lead time 3–10 days (30% faster than industry average)
  • Reliability: 99.6% on - time delivery record tracked via blockchain
  • Cost - Effective: No premium charges for expedited orders over 500kg

Order Now

  • Instant online quotes
  • Free samples dispatched within 24 hours
  • Dedicated account manager for urgent requirements

Your mission - critical sealing needs, delivered at light speed.
Item Standard Value
C concentration 99%
S concentration <1000ppm
chlorine concentration <45ppm
tensile strength 4.5MPa
compressibility >40%
recovery >10%
Temperature -200ºC-600ºC
Pressure 20MPa
Terence of Thickness -0.04mm~+0.04mm
Terence of Dimension In accordance with your Gasket size
Terence of Density -0.06~g/cm3+0.06gcm3

Grades Separate :JB/T53392-1999
Mechanical Data Qualified product Top Grade Superior Grade
Density Tolerance
g/cm3		 <0.4 ±0.10
±0.05
≥0.4 ±0.07
Tensile Strength MPa ≥3.2 ≥4.5 ≥5.0
Compression Ratio % 35~55
Rebound Rate % ≥9 ≥11 ≥12
Stress relaxation rate % ≤10
Ash % ≤6.0 ≤3.0 ≤1.0
Heat loss on ignation % 450ºC ≤1.0 ≤0.5
600ºC ≤20 ≤15

Sulphur content 		≤1500ppm ≤1000ppm ≤600ppm

Chloride content		 ≤100ppm ≤50ppm ≤20ppm
