Specifications
Brand Name :
CLINGSEAL
Model Number :
CSG80
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500kg
Price :
2.2USD PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500Tons per month
Delivery Time :
20 days
Packaging Details :
pallet/wooden case
Grade :
Industrial Grade
C content (%) :
99.9%
Density :
Specific Gravity
Type :
Flexible Sheet
Thickness :
Customizable
Material :
High-Pure Graphite，Graphite,
Fatigue Resistance :
Repeated Stress Resistance
Impact Resistance :
Shock Absorption
Wear Resistance :
Long - Lasting Surface
Description

Products Description

Italian Pump & Valve Graphite Gasket Solutions
Flexible graphite products for Italian pump and valve applications include sheets, foils, papers, tapes, and strips. These materials are produced through chemical intercalation of natural graphite flakes followed by high-temperature exfoliation, creating vermiculate structures with 0.003g/cm³ density. The binder-free expanded graphite is calendared into rolls, offering:
  • 99%+ purity
  • Chemical inertness
  • Radiation resistance
  • Thermal stability (-200°C to +650°C)
  • High compression recovery
  • Self-lubricating properties
  • Gas-tight sealing performance
Ideal for Italian pump and valve sealing systems, these materials can be laminated with metal layers to form composite gaskets.
Key Applications for Italian Industry:
  1. Packing rings for industrial pumps and valves
  2. Custom-shaped gaskets for pump flange sealing
  3. Composite gaskets for valve bonnet applications
  4. High-temperature insulation pads for pump components
Standard & Custom Specifications:
  • Roll Dimensions: 1000mm/1500mm width | 30m/50m/80m length
  • Sheet Size: 1000x1000mm/1500x1500mm
  • Thickness Range: 0.15-5.0mm
  • Density: 0.8-1.25g/cm³
    Special configurations available for Italian pump & valve manufacturers
Item Standard Value
C concentration 99%
S concentration <1000ppm
chlorine concentration <45ppm
tensile strength 4.5MPa
compressibility >40%
recovery >10%
Temperature -200ºC-600ºC
Pressure 20MPa
Terence of Thickness -0.04mm~+0.04mm
Terence of Dimension In accordance with your Gasket size
Terence of Density -0.06~g/cm3+0.06gcm3

Grades Separate :JB/T53392-1999
Mechanical Data Qualified product Top Grade Superior Grade
Density Tolerance
g/cm3		 <0.4 ±0.10
±0.05
≥0.4 ±0.07
Tensile Strength MPa ≥3.2 ≥4.5 ≥5.0
Compression Ratio % 35~55
Rebound Rate % ≥9 ≥11 ≥12
Stress relaxation rate % ≤10
Ash % ≤6.0 ≤3.0 ≤1.0
Heat loss on ignation % 450ºC ≤1.0 ≤0.5
600ºC ≤20 ≤15

Sulphur content 		≤1500ppm ≤1000ppm ≤600ppm

Chloride content		 ≤100ppm ≤50ppm ≤20ppm
