Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Radioactivity Resistance 99% Graphite Gasket Sheet Customizable
Specifications
Brand Name :
CLINGSEAL
Model Number :
CSG80
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500kg
Price :
2.2USD PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
500Tons per month
Delivery Time :
20 days
Packaging Details :
pallet/wooden case
Grade :
Industrial Grade
Hardness :
Shore Hardness
Density :
Specific Gravity
Thickness :
Customizable
Type :
Flexible Sheet
Material :
High-Pure Graphite, Graphite,
C content (%) :
99.9%
Customization :
Tailored Dimensions/Shapes
Industry Application :
Oil & Gas, Chemical, Power
Description

Products Description

Bulk Graphite Gasket Sheet Wholesale
Flexible graphite materials include sheets, foils, papers, tapes, and strips. These products are made by chemically treating natural graphite flakes followed by high-temperature heating to form worm-like structures with a density of about 0.003g/cc. The expanded graphite is rolled into coils without binders, ensuring high purity. Key features:
  • Corrosion resistance
  • Radioactivity resistance
  • High/low temperature resistance
  • Compression resilience
  • Self-lubrication
  • Impermeability
Ideal for low-pressure sealing, these coils can be combined with metal sheets to produce composite plates.
Product Applications:
  1. Material for graphite packing rings
  2. Composite sheets cut into various sealing gaskets
  3. Thick plates for low-pressure gaskets or high-temperature insulation
Standard Specifications:
  • Width: 1000mm/1500mm
  • Coil Length: 30m/50m/80m
  • Plate Size: 1000mm/1500mm
  • Thickness: 0.15-1.0mm (coil) / 1.0-5mm (plate)
  • Density: 0.8-1.25g/cm³
    Custom specifications available upon request
Item Standard Value
C concentration 99%
S concentration <1000ppm
chlorine concentration <45ppm
tensile strength 4.5MPa
compressibility >40%
recovery >10%
Temperature -200ºC-600ºC
Pressure 20MPa
Terence of Thickness -0.04mm~+0.04mm
Terence of Dimension In accordance with your Gasket size
Terence of Density -0.06~g/cm3+0.06gcm3

Grades Separate :JB/T53392-1999
Mechanical Data Qualified product Top Grade Superior Grade
Density Tolerance
g/cm3		 <0.4 ±0.10
±0.05
≥0.4 ±0.07
Tensile Strength MPa ≥3.2 ≥4.5 ≥5.0
Compression Ratio % 35~55
Rebound Rate % ≥9 ≥11 ≥12
Stress relaxation rate % ≤10
Ash % ≤6.0 ≤3.0 ≤1.0
Heat loss on ignation % 450ºC ≤1.0 ≤0.5
600ºC ≤20 ≤15

Sulphur content 		≤1500ppm ≤1000ppm ≤600ppm

Chloride content		 ≤100ppm ≤50ppm ≤20ppm
