EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise
Specifications
Brand Name :
Global Power
Model Number :
GPP20
Certification :
OEM / ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 Set
Price :
Negotiable
Supply Ability :
2000 Sets per Year
Delivery Time :
30 working days after received down-payment
Packaging Details :
Plastic foam or plywood case packing
Type :
Super Silent Type
Prime Power :
20 KVA / 16 KW
Standby Power :
22 KVA / 18 KW
Engine :
Perkins 404D-22G
Alternator :
Meccalte ECP28-M4A
Dimensin(L*W*H) :
2000*1000*1830 MM
Weight :
960 KG
Fuel Tank capacity :
1000 L
Description

EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise


APPLICATIONS:

Home, Buildings, Hospitals, Train station,

Bank, Telecom, Mining, Military, Outdoor projects, etc

rdware constructed from rust resistant materials.

EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise

GENERAL DATA
Standby Power L.T.P. (cosØ=0.8) Kva / kW 18 / 22
Prime Power P.R.P. (cosØ=0.8) Kva / kW 16 / 20
Nominal current Amps 29
Nominal voltage V 400 / 230
Frequency Hz 50
ENGINE Perkins 404D-22G
Emission standard EU III
Engine speed rpm 1500
Engine governor Mechanical / Electric Mechanical
Engine speed regulation % ±2%
Cylinder configuration 4 In line
Cooling type Liquid / Air Liquid
Displacement L 2.216
Engine Power kW 18
Battery charging alternator voltage V 12
ALTERNATOR Meccalte ECP28-M4A
Type Brushless self exciting, synchronic Brushless self exciting, synchronic
Pole / Connecting type 4 / Star Y 4 / Star Y
Insulation class H H
Protection grade IP 23 IP 23
Voltage regulation ±1.5 ±1
Waveform distortions THD % ≦5%

EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise

STANDARD EQUIPMENT:

1. Diesel engine

2. Alternator

3. Starting batteries

4. On engine wiring

5. Fuel tank with on engine fuel installation

6. Elastic engine and alternator mountings

7. Exhaust compensators

8. Silencer

9. On engine liquids (engine oil and cooling liquid, without fuel)

10. Generating set terminal box

11. Main circuit bracer

12. Generating set control panel with engine and alternator parameters indication

13. Emergency stop

14. Acoustic warning signal

EU III 20KVA 0.80 PF Super Silent Diesel Generator Set with Very Low Noise

ACCESSORY:

1. External fuel tank

2. Synchronization with other generator set

3. Ventilation

4. Exhaust piping systme

5. Different protection

6. Other voltage application

7. Individual ATS

8. Spark arrestor

9. Remote control

10. Maintenance contract

11. others
