In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power
Specifications
Brand Name :
Global Power
Model Number :
SU35LHE
Certification :
OEM/ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
Negotiable
Supply Ability :
2,000sets/year
Delivery Time :
25 working days after received down-payment
Packaging Details :
FOB, CRF,CIF,EXW…
Key Words :
Emergency Diesel Generator Set
Output Type :
AC Three Phase
Rated Voltage: :
400/230
Prime Power (kw/kva) :
35/44
Standby Power(kw/kva) :
38.5/48
Engine Model :
K4100-ZD1
Alternator Brand :
GPI 184H
Frequency :
50Hz
Weight(kg) :
700
Dimension Size(L*W*H/mm) :
1700*650*1250
Package :
Plastic Foam or Plywood Case
Control Module Brand :
HGM410
Description

Model: SU35LHE

In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power

Diesel Electric Generator data

Diesel Generator SU35LHE (three phase)

Prime Power (kw/kva) 35/44
Standby Power (kw/kva) 38.5/48
Rated Voltage (V) 400/230
Voltage Recovery Time ≤1S
Rated Current (A) 63
Rated Frequency (Hz) 50
Frequency Recovery Time ≤5S
Wave Distortion ≤5%, sine wave
Running Noise db(A)/7m(Silent type) 75
Battery capacity (V-Ah) 12V 100Ah
Open Type-Dimension (L*W*H) (mm) 1700*650*1250
Open Type-Weight (kg) 700
Base Fuel Tank /
Continuous Running Time(hr.) 8

KOFO Engine specifications

Engine

Main features:

  1. Four-cylinder, water-cooled, in-line diesel engine
  2. Efficient fuel system for max power output and durability
  3. Large-capacity air cleaner
  4. Cost effective, fuel efficient and reliable performance
  5. Functional engine with compact structure
  6. Excellent after-sales service and sufficient spare parts supplying
  7. Easy installation and ready access for routine maintenance

In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power

Technical data

Model K4100ZD1

Engine brand Kofo
Output Power (kw) 42
Cylinder No. & Config. 4, in-line
Combustion System Eddy current
Aspiration type Turbo charged
Displacement (L) 3.6
Bore X Stroke (mm) 100*115
Engine Speed (r/min) 1500
Speed Governing Mechanical / Electric
Starting System 24V DC Electric
Filter System Dry oil filter/Fuel filter/Oil filter
Cooling system Water-cooled
Coolant capacity (L) 13
Fuel Consump. (g/kw·h) ≤235
Oil Capacity (L) 13

Alternator specifications

In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power

Alternator

Main features:

  1. Advanced automatic voltage regulator (AVR) control for trouble-free operation under the most demanding conditions
  2. 2/3 pitch winding as standard, to avoid excessive neutral currents
  3. Single or two bearing construction with dynamically balanced rotor and sealed-for-life bearings
  4. Easy access for installation and maintenance
  5. IP23 as standard
  6. Self-excited control system
  7. Resist of corruption of oil and acid

Technical data

Model GPI 184H

Alternator brand Global Power
Rated Power (kw) 30
Excitation System Brushless, self-exciting
Voltage Regulation Mode AVR
Connection Type 3phase,4wires,”Y” connection
Pole No. 4
Rotation Speed (r/min) 1500
Temperature Rise (℃) 125
Insulation class H
Voltage Regulation (0 load) ≥95%～105%
Voltage accuracy ≤±1%
Protection Grade IP23
Telephone Influence Factor TIF＜50
Harmonic Coefficient THF＜2%

Control system

HGM410 controller

In Line Four Cylinder 3 Phase Diesel Generator Set 35kw 44kva Prime Power

Main features:

  1. Using microprocessor as a core, graphics LCD with big screen and backlight, key touch for operation
  2. Security password-protected programming levels
  3. All parameters use digital modulation, with higher reliability and stability
  4. Built-in speed/frequency detecting units can accurately judge the states such as crank success and over speed
  5. Power supply range is wide, accommodating to different starting battery voltage environment
  6. Built-in watch dog can never be dead halt, ensuring smooth program execution
  7. Modular configuration design, inserted type connection terminals, flush type installation, compact structure, easy installation
