160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
Specifications
Brand Name :
Global Power
Model Number :
GP C160
Certification :
OEM/ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
2000 sets/year
Delivery Time :
25 working days after received down-payment
Packaging Details :
Plastic Foam or Plywood Case
Key Words :
Diesel Power Generator Set
Engine Model :
Cummins, 6CTAA8.3-G2
Alternator brand :
Meccalte, ECO38-2S4A
Frequency :
50Hz
Rated Voltage: :
415/240
Prime Power (kw/kva) :
160/200
Standby Power(kw/kva) :
176/220
Rated Current (A) :
278
Running Noise db(A)/7m(Silent type) :
75(silent type)
Control Module Brand :
SmartGen, Deepsea, ComAp
Battery capacity (V-Ah) :
12V 120Ah*2
Voltage Recovery Time :
≤1S
Description

160kw / 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator

Model: GP C160

Cummins Diesel Generator Set Applications:


Home, Buildings, Hospitals, Train station,
Bank, Telecom, Mining, Military, Outdoor projects, etc.

Features and benefits

  1. Tightly structure, excellent design and craft
  2. Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)
  3. Self-diagnostic capability simplifies troubleshooting
  4. LCD display shows system status and setup information
  5. Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
  6. Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
  7. Enclosed muffler for added quietness
  8. Service and maintenance accessible through easy-latch side service door
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator


Silent Diesel Generator Set data

Diesel Generator GP C160 (three phase)

Prime Power (kw/kva) 160/200
Standby Power (kw/kva) 176/220
Rated Voltage (V) 415/240
Voltage Recovery Time ≤1S
Rated Current (A) 278
Rated Frequency (Hz) 50
Frequency Recovery Time ≤5S
Wave Distortion ≤5%, sine wave
Running Noise db(A)/7m(Silent type) 75
Battery capacity (V-Ah) 12V 120Ah*2
Open Type-Dimension (L*W*H) (mm) 2450*950*1500
Open Type-Weight (kg) 1570
Soundproof Type- Dimension (L*W*H) (mm) 3200*1200*1750
Soundproof Type-Weight (kg) 2486
Fuel Tank Capacity(L) 250
Continuous Running Time(hr.) 8

Cummins Engine specifications


Engine
Main features:

  1. Sixr-cylinder, water-cooled, in-line diesel engine
  2. Efficient fuel system for max power output and durability
  3. Large-capacity air cleaner
  4. Cost effective, fuel efficient and reliable performance
  5. Functional engine with compact structure
  6. Excellent after-sales service and sufficient spare parts supplying
  7. Easy installation and ready access for routine maintenance

160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator

Technical data

Model 6CTAA8.3-G2

Engine brand Cummins
Output Power (kw) 183
Cylinder No. & Config. 6, in-line
Combustion System direct injection
Compression Ratio 16.0:1
Displacement (L) 8.3
Bore X Stroke (mm) 114*135
Engine Speed (r/min) 1500
Speed Governing Electronic
Starting System 24V DC Electric
Filter System Dry oil filter/Fuel filter/Oil filter
Cooling system Water-cooled
Coolant capacity (L) 40
Fuel Consump. (g/kw·h) 205
Oil Capacity (L) 23.8

Meccalte Alternator specifications


Alternator
Main features:

  1. Advanced automatic voltage regulator (AVR) control for trouble-free operation under the most demanding conditions
  2. 2/3 pitch winding as standard, to avoid excessive neutral currents
  3. Single or two bearing construction with dynamically balanced rotor and sealed-for-life bearings
  4. Easy access for installation and maintenance
  5. IP23 as standard
  6. Self-excited control system
  7. Resist of corruption of oil and acid


Technical data

Model ECO38-2S4A

Alternator brand MECCALTE
Rated Power (kw) 160
Excitation System Brushless, self-exciting
Voltage Regulation Mode AVR
Connection Type 3phase,4wires,”Y” connection
Pole No. 4
Rotation Speed (r/min) 1500
Temperature Rise (℃) 125
Insulation class H
Voltage Regulation (0 load) ≥95%～105%
Voltage accuracy ≤±1%
Protection Grade IP23
Telephone Influence Factor TIF＜50
Harmonic Coefficient THF＜2%


Control system
160kw 200kva Canopy Cummins Diesel Power Generator Set With Meccalte Alternator
HGM410 controller

Main features:

  1. Using microprocessor as a core, graphics LCD with big screen and backlight, key touch for operation
  2. Security password-protected programming levels
  3. All parameters use digital modulation, with higher reliability and stability
  4. Built-in speed/frequency detecting units can accurately judge the states such as crank success and over speed
  5. Power supply range is wide, accommodating to different starting battery voltage environment
  6. Built-in watch dog can never be dead halt, ensuring smooth program execution
  7. Modular configuration design, inserted type connection terminals, flush type installation, compact structure, easy installation
