MTU Engine 12V2000G65 Heavy Duty Dg Genset 24V DC Electric 50hz 600KW 750KVA Prime
MTU Engine 12V2000G65 Heavy Duty Dg Genset 24V DC Electric 50hz 600KW 750KVA Prime
MTU Engine 12V2000G65 Heavy Duty Dg Genset 24V DC Electric 50hz 600KW 750KVA Prime
MTU Engine 12V2000G65 Heavy Duty Dg Genset 24V DC Electric 50hz 600KW 750KVA Prime
Specifications
Brand Name :
Global Power, MTU
Model Number :
GP M2250
Certification :
CE / ISO
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
negotiable
Supply Ability :
2000 sets / year
Delivery Time :
25 days after receiveing the down-payment
Packaging Details :
plastic foam or plywood case packing
Engine Brand: :
MTU
Alternator: :
Stamford
Engine Model: :
12V2000G65
Rated Frequency (Hz) :
50/60 hz
number of phase :
3
Dimension L*W*H/mm :
4050*1700*2150
Weight/kg :
6100
Alternator :
LVI 634B
Description

MTU Engine 12V2000G65 Heavy Duty Diesel Generator 24V DC Electric 50hz 600KW / 750KVA Prime


Product Description:
1. Power range: 250kva-3000kw
2. Application: construction machinery, home uses, Industry,aviation,vehicle,etc.
3 Advantage: MTU series has a high reputation with super quality, mainly on big power.

Prime Power (kw/kva) 600/750
Standby Power (kw/kva) 660/825
Rated Voltage (V) 400/230
Voltage Recovery Time ≤1S
Rated Current (A) 1083
Rated Frequency (Hz) 50
Frequency Recovery Time ≤5S
Wave Distortion ≤5%, sine wave
Running Noise db(A)/7m(Silent type) 115
Battery capacity (V-Ah) 12V 100Ah
Open Type-Dimension (L*W*H) (mm) 4050*1700*2150
Open Type-Weight (kg) 6100
Soundproof Type- Dimension (L*W*H) (mm) /
Soundproof Type-Weight (kg) /
Fuel Tank Capacity(L) /
Continuous Running Time(hr.) 6


Engine specifications

Engine
Main features:

  • Twelve-cylinder, water-cooled, in “V” diesel engine
  • Efficient fuel system for max power output and durability
  • Large-capacity air cleaner
  • Cost effective, fuel efficient and reliable performance
  • Functional engine with compact structure
  • Excellent after-sales service and sufficient spare parts supplying
  • Easy installation and ready access for routine maintenance


Technical data

Model 12V2000G65

Engine brand MTU
Output Power (kw) 695
Cylinder No. & Config. 12,in “V”
Combustion System direct injection
Compression Ratio 16:1
Displacement (L) 23.88
Bore X Stroke (mm) 130*150
Engine Speed (r/min) 1500
Speed Governing Electronic / ADEC
Starting System 24V DC Electric
Filter System Dry oil filter/Fuel filter/Oil filter
Cooling system Water-cooled
Coolant capacity (L) 164
Fuel Consump. (g/kw·h) 198
Oil Capacity (L) 77


MTU Engine 12V2000G65 Heavy Duty Dg Genset 24V DC Electric 50hz 600KW 750KVA Prime
Features and benefits

  • Tightly structure, excellent design and craft
  • Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)
  • Self-diagnostic capability simplifies troubleshooting
  • LCD display shows system status and setup information
  • Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
  • Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
  • Enclosed muffler for added quietness
  • Service and maintenance accessible through easy-latch side service doo
