Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set
Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set
Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set
Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set
Specifications
Engine Brand: :
Cummins,perkins, MTU.Xuchai,Vman,Doosan..available
Rated Power (kw): :
24/30
Alternator Brand: :
Stamford / Meecalt / Copy Stamford
Engine Model: :
KOFO-K4100DS/30
Frequency (Hz) :
50 OR 6O hz
Generator Type: :
open, soundproof, mobile trailer
Controller Brand :
Comap,SmartGen, DeepSea
Control Module :
HGM410
Loading Port :
Shanghai, Ningbo.....
Power Range of Cummins :
25-125kva
Brand Name :
Global Power
Model Number :
GPk24
Certification :
CQC / ISO
Place of Origin :
Jiangsu, China
MOQ :
1 set
Price :
negotiable
Supply Ability :
2000 sets / year
Delivery Time :
25 days after receiveing the down-payment
Packaging Details :
plastic foam or plywood case packing
Description

Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set

Specification of Genset
Genset model GPK24
Prime power 30KVA/24KW
Standby power 33KVA/26KW
Rated frequency 50HZ
Rated speed 1500RPM
Noise Level 72dB(A)@7m
Specification of Diesel Engine
Engine brand&model WEICHAI (Kofo) K4100DS
No of cylinders 4
Cylinder arrangement Vertical in-line
Cycle Four stroke
Aspiration Water cooling, natural aspirated
Bore*stroke

100×115
Displacement 3.61
Speed governor Electronic
Cooling system Forced water cooling cycle
Fuel consumption at 100% load 243g.kw/h
Starting method DC12V electrical starting
Specificaion of Alternator
Alternator brand&model brushless alternator GP184G
No. of phase 3
Connecting type 3 Phase and 4 Wires
No. of bearing 1
Protection grade IP 23
Insulation class H
Altitude ≤1000m
Exciter type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Telephone influence factor(TIF) ≤50
THF ≤2%
Voltage regulation, Steady state ≤±1%
Transient state voltage ≤-15%~+20%
Specification of Control Panel
Brand&Model SmartGen-HGM410
The control panel is equipped with display of voltage, current, frequency, water temperature, oil pressure.
The genset with low oil pressure, high water temperature, over speed and over load protection function.

Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set

Package:

Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set

Features and benefits

l Tightly structure, excellent design and craft

l Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)

l Self-diagnostic capability simplifies troubleshooting

l LCD display shows system status and setup information

l Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality

l Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.

l Enclosed muffler for added quietness

l Service and maintenance accessible through easy-latch side service door

Quality control of Global power Genset

Thick Soundproof Canopy Generator Set Water Cooled / Diesel Engine Weichai Generator Set

1. The genset canopy can be designed by customers demand free of charge.

2. Noise level can be designed by customer demand, standard noise level is 70-73DB at 7m. Super silent is 60-65DB at7m.

3. Canopy color can be painted free of charge by customer demand. It is high quality paint.

4. All connection components and door lock are stainless steel.

5. We added oil filling inlet with lock

6. The oil box is separate madeand then welded to the base frame, not by simple welding on the base frame. It is to make sure there is no oil leakage

7. The base frame is with forklift mouthwhich is easy to load and discharge

8. For Logo, we can paint customer's logo when the order is more than 5sets.

9. For technical specification or question, we can support you by our strong technical team.
