Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels
Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels
Specifications
Brand Name :
LONGYU
Certification :
ISO9001
MOQ :
1Set
Price :
USD:3000-4000
Payment Terms :
T/T
Supply Ability :
10Sets/month
Delivery Time :
10-30 days
Packaging Details :
Standard wooden case
Max. Treatment Width :
1300 mm
Target Material :
SPC, Aluminum, Non-metallics
Key Benefit :
Enables Strong Adhesive Bonding
Electrode material :
Stainless steel or tungsten
Material :
Ceramic Electrode
Frequency :
High frequency, usually 50-60 kHz
Usage :
Material Surface Treatment
Length :
Customer requirements
Description

Corona Surface Treater Machine 1300mm Width, 12m/min for SPC and Aluminum Panels

Specifications:

Technical Parameter

Specification

Model Number

LY-09-1300

Main Application

Surface activation for improved adhesion

Max. Corona Treatment Width

1300 mm (Optional)

Max. Production Line Speed

12 m/min

Applicable Board Thickness

1 - 3 mm (Non-metallic materials, Optional)

Min. Board Size (for processing)

1-1.3 m (W) × 0.5 m (L)

Target Materials

SPC, Aluminum Plates, various non-metallics

Power Supply

220V 50Hz Single-Phase AC (Optional)

Max. Power Consumption

6 KW

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels

Notices:

1. Safety First: The equipment generates high voltage. Ensure proper grounding, installation of safety interlocks, and operator training before use.

2. Material Compatibility: Verify that the material to be treated is compatible with corona discharge and falls within the specified thickness and width range.

3. Maintenance: Regular cleaning of the electrode and dielectric roller is essential to maintain consistent treatment quality and prevent arcing.

4. Process Validation: The treatment effect is not permanent (shelf-life effect). It is recommended to perform the coating, printing, or lamination process shortly after treatment for optimal results.

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels

Applications:
Essential for preparing material surfaces prior to any bonding or coating operation in panel manufacturing:

1. Pre-lamination Treatment: Treating SPC or aluminum facing sheets before they enter the LY-07-3000 Laminating Machine to ensure superior glue adhesion.

2. Printing & Coating: Activating surfaces for direct digital printing, painting, or film application on panels.

3. General Plastic & Foil Treatment: Enhancing the bondability of various non-porous, low-surface-energy materials.

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels

Strong Adhesive Bonding Corona Surface Treater for SPC / Aluminum Panels
