Specifications
RAted Operate Volatge :
AC 380-690V
Shell protection rating :
IP33, Customizable To IP54
Place Of Origin :
China
Rated Current :
260A
Price :
Interview
Model Number :
GHHX-B-60
Equivalent Copper Cable Cross-section :
60mm²
Environmental Indicators :
Ambient Temperature: -25℃-40℃, With The Average Temperature Variation Not Exceeding 35℃ Within Any 24-hour Period; Relative Humidity Can Reach 100% At An Ambient Temperature Of 25℃.
Rated peak withstand current :
6.75KA
Number of Poles :
5P
Brand Name :
GHEC
Electrothermal stability :
Imes Rated For 1s
Description
Vibration and Shock Resistance 10-2000HZ Sliding Contact Lines
Product Overview

Advanced moving contact line system designed for high-performance electrical transmission applications. This system ensures efficient and stable power transmission in various industrial and commercial environments.

Key Compliance: GB/T 7251.6 - 2015 Low-Voltage Switchgear and Controlgear standards for busbar trunking systems

Insulation Resistance: Greater than 5 MΩ between poles and between poles and ground

Cable Capacity: Incoming cable copper core cross-section of 70mm²

Configuration: Dual current collectors with five-pole (5P) design

Product Features
  • Product Name: Sliding Contact Lines
  • Acceleration: 49m/S²
  • Corrosion Stability: Acid-resistant, Alkali-resistant, Salt Spray Corrosion-resistant
  • Number of Poles: 5P
  • Electrothermal Stability: Imes Rated for 1s
  • Flame Retardancy: V0 Grade
  • Designed as a reliable Moving Contact Line System
  • Enhanced durability for demanding applications
  • Optimized performance for industrial environments
Technical Specifications
Environmental Indicators Ambient Temperature: -25℃ to 40℃, with average temperature variation not exceeding 35℃ within 24 hours; Relative humidity up to 100% at 25℃
Transmission Guide Rail Parameters Compliant with GB/T 7251.6 - 2015 Low-voltage switchgear and controlgear standards
Net Weight Per Single Rail 13.75 kg
Rated Operate Voltage AC 380-690V
Withstand Current 4.5 kA
Number of Poles 5P
Effective Service Length 3016 mm
Shell Protection Rating IP33, customizable to IP54
Incoming Cable (Copper Core) 70 mm²
Equivalent Copper Cable Cross-section 60 mm²
Applications

Model: GHEC Sliding Contact Lines (GHHX-B-60)

This moving contact line system is engineered for demanding industrial applications requiring continuous and stable electrical power transfer to moving equipment.

Primary Application Areas:
  • Automated factories and assembly lines
  • Crane operations and material handling systems
  • Electric railways and trolleybuses
  • Mining operations and logistics centers
  • Warehouses and transportation sectors
  • Environments with high humidity or temperature fluctuations

The system's robust design and compliance with environmental standards make it suitable for both indoor and outdoor applications where equipment mobility and reliable power delivery are essential.
