Specifications
Electrothermal stability :
Imes Rated For 1s
Environmental Indicators :
Ambient Temperature: -25℃-40℃, With The Average Temperature Variation Not Exceeding 35℃ Within Any 24-hour Period; Relative Humidity Can Reach 100% At An Ambient Temperature Of 25℃.
Matching Current Collector Model :
GHJD-B-130A
altitude :
Below 2000 Meters
Brand Name :
GHEC
Incoming Cable (Copper Core) :
70mm²
Rated peak withstand current :
6.75KA
Flame retardancy :
V0 Grade
Price :
Interview
Model Number :
GHHX-B-60
Place Of Origin :
China
Withstand current :
4.5KA
Description
Guide Rail Parameters Compliant With GB T 7251 6 2015 Sliding Contact Lines
Product Overview

The Sliding Contact Lines product is a highly reliable and durable component designed for advanced electrical applications where consistent and stable current transfer is essential. This critical part of the Moving Contact Line System ensures uninterrupted electrical connectivity between stationary and moving components in various industrial environments.

Key features include exceptional electrothermal stability (Imes rated for 1 second), high peak withstand current capacity (6.75KA), and superior corrosion resistance against acid, alkali, and salt spray environments.
Product Features
  • Product Name: Sliding Contact Lines
  • Electrothermal Stability: Imes Rated For 1s
  • Rated Operating Voltage: AC 380-690V
  • Insulation Resistance: >5MΩ between poles and between poles
  • Transmission Guide Rail Parameters: Compliant With GB/T 7251.6-2015
  • Corrosion Stability: Acid-resistant, Alkali-resistant, Salt Spray Corrosion-resistant
  • Moving Contact Line System for reliable electrical transmission
  • Includes 2 current collectors for enhanced reliability
  • Effective service length: 3016mm
Technical Specifications
Parameter Specification
Rated Peak Withstand Current 6.75KA
Incoming Cable (Copper Core) 70mm²
Vibration and Shock Resistance 10-2000HZ
Shell Protection Rating IP33, Customizable To IP54
Withstand Current 4.5KA
Electrothermal Stability Imes Rated For 1s
Net Weight Per Single Rail 13.75kg
Rated Operate Voltage AC 380-690V
Number of Poles 5P
Acceleration 49m/S²
Applications

The GHEC Sliding Contact Lines (model GHHX-B-60) are designed for efficient power transmission in various industrial applications requiring dynamic and continuous movement:

  • Automated production lines
  • Overhead cranes and conveyor systems
  • Rail transit systems
  • Factory automation and robotic assembly lines
  • Heavy industrial settings and manufacturing environments

This lightweight yet robust solution (13.75kg per single rail) ensures stable and continuous current flow with high insulation resistance (>5MΩ) for enhanced safety and operational longevity.
