Specifications
Model Number :
GHHX-B-60
RAted Operate Volatge :
AC 380-690V
Brand Name :
GHEC
Price :
Interview
Transmission guide rail parameters :
Guide Rail Parameters Compliant With GB/T 7251.6 - 2015 Low - Voltage Switchgear And Controlgear - Part 2:<< Particular Requirements For Busbar Trunking Systems (busway)>>
Place Of Origin :
China
Matching Current Collector Model :
GHJD-B-130A
Rated peak withstand current :
6.75KA
Electrothermal stability :
Imes Rated For 1s
Effective Service Length :
3016mm
Flame retardancy :
V0 Grade
Rated Current :
260A
Description
Incoming Cable Copper Core 70mm² Moving Contact Line System
Product Overview

The Sliding Contact Lines product is a highly reliable and efficient component designed for Moving Contact Line System applications. Engineered to withstand demanding operational conditions, this solution ensures seamless electrical connectivity for smooth, uninterrupted power transmission in various industrial and transportation settings.

Operating effectively within an ambient temperature range of -25℃ to 40℃, this system handles average temperature variations not exceeding 35℃ within any 24-hour period, ensuring stable performance in fluctuating conditions.

With relative humidity tolerance reaching 100% at 25℃ ambient temperature, this product is ideal for high-moisture environments such as coastal areas or humidity-controlled facilities, preventing corrosion and extending system lifespan.

Key Features
  • Product Name: Sliding Contact Lines
  • Effective Service Length: 3016mm
  • Incoming Cable (Copper Core): 70mm²
  • Net Weight Per Single Rail: 13.75kg
  • Withstand Current: 4.5KA
  • Rated Peak Withstand Current: 6.75KA
  • Designed as a reliable Moving Contact Line System
  • High durability for continuous operation
  • Optimized for performance and safety in installations
Technical Specifications
Number of Poles 5P
Net Weight Per Single Rail 13.75kg
Transmission Guide Rail Parameters Compliant With GB/T 7251.6-2015 Low-Voltage Switchgear And Controlgear
Shell Protection Rating IP33, Customizable To IP54
Withstand Current 4.5KA
Rated Operate Voltage AC 380-690V
Matching Current Collector Model GHJD-B-130A
Rated Current 260A
Electrothermal Stability Rated For 1s
Rated Peak Withstand Current 6.75KA
Applications

The GHEC Sliding Contact Lines, model GHHX-B-60, are engineered for demanding electrical transmission and distribution applications requiring continuous power transmission along moving equipment.

Ideal for manufacturing plants, warehouses, and transportation hubs where heavy-duty electrical conduction is critical. Commonly applied in overhead crane systems, rail transit systems, automated guided vehicles (AGVs), and assembly lines.

With rated current of 260A and peak withstand current of 6.75KA, this system supports high-load scenarios while maintaining stable, uninterrupted power supply. The insulation resistance between poles exceeds 5MΩ, ensuring high safety and minimal leakage current.
