1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Genyu
MOQ :
1000
Display Type :
DFSTN
Display Size :
1.3 inch
Resolution :
128x64
Operating Temperature :
-30℃~70℃
Storage Temperature :
-30℃~85℃
Viewing Angle :
3 O'clock
Drive Method :
1/65 Duty,1/9 Bias,Vop=9.0V, VDD=2.8V
Driver IC :
AIP31567A
Backlight Type :
2PCS WHITE LED, If=30mA & Vf=3.0±0.20V
Module Size :
26.7mm(W)*19.26mm(H)*2.3mm(T)
Active Area :
21.744mm(W)x10.864mm(H)
Interface :
RGB
Display Mode :
DFSTN/Transmissive/Negative
Connector Type :
COG+FPC
Backlight Voltage :
3.0±0.20V
Description
1.3 Inch 128x64 LCD Module - High Contrast Display Screen
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Technical Specifications
LCD Size1.3 inch
Panel TypeDFSTN
Resolution128×64
Viewing Direction3 O'clock
Module Size26.7mm(W)×19.26mm(H)×2.3mm(T)
Panel Active Area21.744mm(W)×10.864mm(H)
InterfaceRGB
Operating Temperature-30℃ to +70℃
Storage Temperature-30℃ to +85℃
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
About Genyu Optical
Established in 2003, Shenzhen Genyu Optical Co., Ltd. specializes in R&D, production, and sales of LCD displays, OLED, and TFT LCD modules. We provide professional custom LCD screens including TN, HTN, STN, FSTN, VA (BTN), COG, and COB LCD modules.
Genyu's plant covers approximately 30,000 square meters with 1,000 employees, including 36 technicians, 16 developers, and 60 quality control staff. Our core team includes LCD experts, process engineers, R&D engineers, and backlight/FPC specialists.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
We design, develop, and produce customized LCD, LCM, backlight, FPC, and related products according to customer requirements. Current annual production capacity reaches 100 million LCD screens, 30 million LCMs, and 40 million backlights.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Cleanroom Manufacturing
Our nearly 6,000 square meter dust-free workshop maintains a 100k cleanliness level. Facility features include fully enclosed material transfer windows and air shower systems that effectively remove dust and contaminants from personnel, ensuring product quality.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Our Product Range
Custom Segment LCD Display
Genyu has produced tens of thousands of segment LCDs. We offer TN, STN, HTN, FSTN, and VA/BTN LCD display technologies with custom design capabilities.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Dot Matrix Graphic LCD Display
Available sizes include: 96×16, 96×24, 122×32, 132×36, 132×96, 128×32, 128×64, 128×96, 160×32, 160×80, 192×64, 240×80, 128×128, 160×160, up to 320×240 dot matrix LCD displays.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
AMOLED Display
Mini size OLED displays available in: 0.42", 0.49", 0.66", 0.78", 0.87", 0.91", 0.96", 1.3", 1.54", 2.08", 2.3", 2.4" sizes.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
TFT LCD Display
HD full color TFT LCD displays available in: 0.91", 1.0", 1.28", 1.3", 1.44", 1.54", 1.77", 2.0", 2.2", 2.4", 2.8", 2.95", 3.13", 3.2", 3.5", 4.3", 7", 10.1" sizes.
Features: Standard sizes, standing stock, samples available.
Application Areas
Wearable Device
Medical
Financial
Industrial
New Energy
Communication
Instrumentation
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Quality Assurance
All products undergo strict inspection before packaging to ensure highest quality standards.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Packaging Solutions
Each COG LCD product features custom plastic containers with professional blister packaging that securely fixes each LCD product during transport.
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
Shipping Information
Carton size: 398 × 331 × 430 mm | Weight: approximately 17 kg
Items ship within 3 working days after payment confirmation.
  • DHL/UPS/FedEx/TNT: 2-5 working days
  • EMS: 7-10 working days
  • CPAM/HKPAM: 10-30 working days
1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen1.3 Inch 128x64 High Contrast LCD Module TFT LCD Display Screen
