Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Automatic Spray Pump Assembly Machine for Medical Equipment
Specifications
Advantage :
High Efficiency
video outgoing-inspection :
Provided
warranty :
1 Year
After-sales Service Provided :
Field installation, commissioning and training
Operation :
Easy Automatic Operation
Type :
y500, Assembly machine
Application :
Lotion pump assembly machine
Package :
Standard Wooden Package
key selling points :
High-Accuracy
Warranty :
One Year
Place of Origin :
China
Capacity :
y800
Local Service Location :
None
Packaging Details :
Wooden
machinery test report :
Provided
Payment Terms :
TT
Supply Ability :
10 PCS
MOQ :
1 set
Delivery Time :
90~150 days
Brand Name :
Gereke
core components :
PLC, Bearing, Motor, Fitting mechanism
weight (kg) :
2000
Certification :
CE ISO90001
After Warranty Service :
Online support
Description
Products Description

Lotion Pump automatic assembly Machine-cosmetic machine

The assembly will auto feeding the house , pump core ,spring ,ball and screw cap ,and automatic through detect the exist and the direction ,then automatic assembly together .
Automatic Spray Pump Assembly Machine for Medical Equipment
Manufacturing Technique
1,cassette base shell feed ->2 direction (upward and downward)check->3 Orientation for upward and downward->4 direction (front and back)check->5 Orientation for front and back->6 strip fitting ->7 strip check->8 cassette top shell fitting->9 top shell check ->10 .top and base shell together and pressure->11 push the finish production to the conveyor
->12 push the cassette to packaging machine->13 cassette check->14 bag feeding->15 bag check->16 desiccant feeding ->desiccant check->17 open the bag ->18 push the cassette and desiccant to the bag->19 check it ->20 Sealing the bag->21 defect part ejection ->22 Discharge for the good production
Product Paramenters
Voltage
380VAC /50HZ,15A
Power
3000W
Dimension
2500*2100*1800 mm
Weight
2200kg
Air Pressure
0.5~0.8MPa
Operating Speed
60-65 pcs/min
Frequency
50hz
Company Profile
Guangdong Gereke Machinery Co., Ltd is a technology industry which incorporating AI into their medical
product range. We have established a strong team of capable staff who concentrate on their own area of ex
pertise. Gereke carries out customizations professionally according to the user’s needs. The entire process
from designing to assembling and packaging are constantly evaluated and improved. We conduct strict and
rigorous test on the quality and performance of the machinery to ensure that the internationally advanced st
andards of the product are there. The excellence in quality and performance has won the complete trust of
many customers.
