2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
2 Ton Natural Gas Hot Water Boiler For Central Heating 2t/H Rated Capacity
Specifications
Brand Name :
SWET
Model Number :
LNS2
Certification :
ISO9001
Place of Origin :
HENAN,CHINA
MOQ :
1 SET
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1200 Sets / Year
Delivery Time :
20work days
Packaging Details :
Wooden boxes plus plastic paper packaging
Rated capacity/t/h :
2
Working pressure/MPA :
1.25
Steam temperature/℃ :
193
Feed temperature/℃ :
20
Testing efficiency/% :
95.81
Gas consumption/Nm3/h :
163.72
Description

2 Ton Industrial Natural Gas Fired Hot Water Boiler For Central Heating

High thermal efficiency

100% corrugated furnace and spirally corrugated tube, can absorb flame heat effectively, thermal efficiency can be more than 96%.

Novel appearance

Boiler outer packing with novel appearance: color coated steel plate and hinged front and back smoke box.

PLC full automatic control system

PLC modular control system enhanced energy management system, offers significant advancements including many new individual monitoring points. With our optimized parameter setting ,the easy-to-use interface provides your facility with an intelligent boiler system to optimize energy and personnel management for increased productivity, efficiency and a reduced environmental impact.

LNS series automatic gas (oil) steam energy saving boiler product selection form
Model Rated capacity Working pressure Steam temperature Feed temperature Testing efficiency Diesel consumption Gas consumption Outline dimension
Unit t/h Mpa ℃ ℃ ％ Kg/h Nm³/h mm(H*W*L)
LNS20-1.25(1.6)-Q(Y) 20 1.25/1.6 194/204 105 97.51 1276.63 1459

8870*3550

*3750
LNS15-1.0(1.25)(1.6)-Q(Y) 15 1.0/1.25/1.6 184/197/204 105 97.2 985.25 1126

7450*3520

*4090
LNS10-1.25(1.6)-Q(Y) 10 1.25/1.6 194/204 105 96.75 732.59 837.25

6370*2812

*3514
LNS8-1.25(1.6)-Q(Y) 8 1.25/1.6 194/204 105 96.7 576.84 659.25

6000*2920

*3403
LNS6-1.25(1.6)-Q(Y) 6 1.25/1.6 194/204 105 96.58 379.32 433.51

5470*2770

*3195
LNS5-1.25(1.6)-Q(Y) 5 1.25/1.6 194/204 20 96.48 358.16 409.33

5160*2410

*3015
LNS4-1.0(1.25)(1.6)-Q(Y) 4 1.0/1.25/1.6 184/197/204 20 96.3 292.45 334.23

4880*2710

*2600
LNS3-1.0(1.25)(1.6)-Q(Y) 3 1.0/1.25/1.6 184/197/204 20 95.99 214.48 245.12

4762*2447

*2469
LNS2-1.0(1.25)-Q(Y) 2 1.0/1.25 184/197/204 20 95.81 143.26 163.72

4030*2010

*2210
Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output
