4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
4.2Mw Commercial Hot Water Boiler Automatic Control Corrosion Resistance
Specifications
Brand Name :
SWET
Model Number :
QXS(SZS)4.2-1.6-Y,Q-3014
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Leaving Water Temperature :
95(115)(130) ℃
efficiency :
95.57 %
Model :
QXS(SZS)4.2-1.6-Y,Q-3014
Keywords :
hot water boiler
Rated thermal power :
4.2 MW
nominal working pressure :
1.25(1.6) MPa
Description

High Efficiency 4.2Mw Automatic Control Hot Water Boiler For Commercial


Product description

1. SZS-type oil-fired gas boiler is a dual-drum vertical type "D" type arrangement quick assembly water tube boiler

2. In order to ensure the ignition of the boiler, the top of the boiler is designed with explosion-proof door. Furnace with manhole, the boiler safe, reliable, and easy to maintain.

Product advantages

1. low power consumption

2. high thermal efficiency

3. good environmental protection effect

4. easy operation and good maintainability

5. convenient operation and convenient installation

Customer visit


1. China Petroleum Pipeline Materials and Equipment Corporation.

2. China Petroleum & Chemical Corporation.

3. China Aero Engine Group.

4. COFCO Group Limited.

Product parameters

SZS water pipe type full automatic gas-fired hot water energy-saving boiler

Model

Rated thermal power

nominal working pressure

Leaving Water Temperature

return water temperature

efficiency

gas consumption

Overall dimensions of transportation

Unit

MW

MPa

℃

℃

%

Nm³/h

mm

QXS(SZS)58

58

1.25(1.6)(2.5)

130(150)

70(90)

98.3

6196

15360*7570*8318

QXS(SZS)48

48

1.25(1.6)(2.5)

130(150)

70(90)

98.09

5048

15600*9500*7920

QXS(SZS)29

29

1.25(1.6)

130(150)

70(90)

97.8

3150

9685*6870*7180

QXS(SZS)21

21

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.13

2328

10130*6170*6134

QXS(SZS)14

14

1.0(1.25)(1.6)

115(130)(150)

70(90)

97.02

1558

8120*3385*3750

QXS(SZS)10.5

10.5

1.0(1.25)(1.6)

115(130)(150)

70(90)

97

1136

7250*3682*3820

QXS(SZS)7

7

0.7(1.0)(1.25)

95(115)(130)

70(90)

96.87

754

6770*3210*3775

QXS(SZS)7

7

1.25

115

70(90)

95.76

763

6760*2780*3299

QXS(SZS)5.6

5.6

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.57

619.2

6450*2956*3620

QXS(SZS)4.2

4.2

0.7(1.0)(1.25)

95(115)(130)

70(90)

95.36

456.7

5700*3105*3410

Performance features: symmetrical furnace, uniform distribution, good cooling, sufficient combustion, long service life, stable output
