Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate
Specifications
Brand Name :
GNEE
Certification :
ISO9001,SGS
Place of Origin :
China
MOQ :
10 square meter
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
100 ton/week
Delivery Time :
5-9 working days
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Press-locked steel grating is fully welded by flat bar,(smooth flat bar, serrated flat bar, I shape flat bar), it also can be called pressure locked grating, it is made of low carbon steel or stainless steel. With the performance of high bearing capacity, non-slip, anti-corrosion and easy to install and remove, pressure locked grating is widely used for ceilings, platforms, floors, fence and all kinds of cover in the factories, civil and commercial buildings.

Two press-locked steel grating with different mesh sizes which people often use: 33 mm × 33 mm, 33 mm × 11 mm.

  • Light weight. high bearing capability and high strength.
  • Non-silp. anti-corrosion.
  • Not easy to deform
  • Beautiful appearance.
  • Easy to install and remove.
  • Extended the lifespan.

Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate

Applications of press-locked steel grating

Press-locked steel grating is widely used for the floor, ceiling, platform, fence, shelf, decoration of outer wall, sun visor, bridge and inner and spiral staircases in such place:

  • Large-scale shopping malls
  • Construction industry.
  • Factories. subway stations.
  • Offshore drilling platforms.
  • Ships.
  • Terminals.
  • Other industrial and civil construction

Welded Swaged Pressure Locked Metal Serrated Steel Grating Plate

Bearing bar pitch Cross bar pitch load steel size ( Width ×Thickness)
20×3 25×3 32×3 40×3 20×5 25×5
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50 - G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Bearing bar pitch Cross bar pitch load steel size (Width ×Thickness)
32×5 40×5 45×5 50×5 55×5 60×5
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50
