High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable
Specifications
Insulation Material :
XLPE
Price :
usd 0.49 ～ 4.58/ meter
Jacket :
PVC
Sample :
Free
Type :
High Voltage
Service :
ODM OEM Accepted
Place of Origin :
Shaanxi, China
Rated Voltage :
8.7-15kv, 8.7/15KV
Model Number :
yjv22
Rated Current :
16 A
Delivery :
10-25days After Received The Prepayment
Certification :
CE，VDE,SO 9001
MOQ :
1000
Delivery Time :
30 days
Application :
Industrial, Construction, Urban power grids, substations, underground cable tunnels
Working Temperature :
0-90℃
Packaging Details :
Wooden Drum、cardboard box、wooden pallet
Supply Ability :
800–1500 kilometers per month
Size :
4-300mm2
MOQ :
1000m
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Conductor Material :
Copper
Brand Name :
F.T
Description

High-voltage Cable YJV22 3*400mm² Steel Tape-armoured Copper Core Underground Power Cable

Technical Specifications (High-voltage Cable YJV22 3*400mm²)

Parameter Technical Details (IEC 60502-2 Standard)
Model YJV22 (CU/XLPE/PVC/STA/PVC)
Specification 3-Core x 400mm² (Underground Power Cable)
Voltage Rating 6/10kV, 8.7/15kV, 12/20kV, 18/30kV
Conductor Material 99.99% High-Purity Oxygen-Free Copper
Insulation Material Cross-linked Polyethylene (XLPE)
Armoring Type Double Steel Tape Armored (STA)
Outer Sheath High-Density Flame Retardant PVC
Max. Operating Temp 90°C (Normal) / 250°C (Short Circuit)
Application Direct Burial, Cable Tunnel, Industrial Power Grid

Key Advantages of 3*400mm² Underground Power Cable

Superior Mechanical Protection

The dual-layer Steel Tape Armor (STA) provides 360° protection against high radial pressure and accidental mechanical impact, making it the "Gold Standard" for direct burial.

High Current Carrying Capacity

The 3*400mm² core utilizes class 2 stranded copper, minimizing power loss and ensuring stable transmission for heavy industrial loads.

Extreme Durability

XLPE insulation offers excellent thermal stability and chemical resistance, extending the cable's service life to over 25 years.

Pest & Rodent Resistance

The robust steel layer forms an impenetrable barrier against rodent attacks in underground tunnels.

Structural Anatomy of YJV22 3*400mm²

  1. Conductor: Annealed stranded copper (Class 2) for maximum conductivity.
  2. Conductor Screen: Semi-conductive material to uniform electrical stress.
  3. Insulation: High-quality XLPE for superior dielectric strength.
  4. Insulation Screen: Semi-conductive layer for electrical field optimization.
  5. Metallic Screen: Copper tape screen for grounding and fault current protection.
  6. Inner Sheath: PVC bedding layer to protect core insulation.
  7. Armor: Double Steel Tape (STA) for heavy-duty mechanical shielding.
  8. Outer Sheath: UV-resistant, flame-retardant PVC (ST2).

High Voltage Cable YJV22 3 X 400mm2 Steel Tape Armoured Copper Core Underground Power Cable

Application Scenarios

Optimized for high-voltage infrastructure and heavy industrial power networks.
