YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable
Specifications
Conductor Material :
Copper
Delivery Time :
7-15 Working Days
Service :
ODM OEM Accepted
Supply Ability :
800–1500 kilometers per month
Type :
Hihg Voltage
Brand Name :
F.T
Model Number :
yjv22
Certification :
CE，VDE,SO 9001，ul
Price :
usd 0.14 ～ 1.28/ meter
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
MOQ :
1000
Application :
Construction, Industrial
Place of Origin :
china
Packaging Details :
Wooden Drum、cardboard box、wooden pallet
Insulation Material :
XLPE
Rated Voltage :
0.6/1KV
Description

YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable

Product Overview

YJV22 High Voltage Cable is a high-performance power transmission cable specifically designed for industrial high-voltage scenarios, featuring 10-300mm² cross-section, XLPE insulation, and steel tape armored structure. As a professional buried industrial electrical cable, it is engineered to meet the high-voltage power transmission and distribution needs of industrial plants, infrastructure projects, and underground laying scenarios, with excellent stability, corrosion resistance and mechanical protection. Complying with GB/T and IEC international standards, this cable ensures safe and efficient long-term operation even in harsh industrial environments.

YJV22 Cable Structure

  • Conductor: High-purity stranded copper conductor.
  • Insulation: Cross-linked polyethylene (XLPE) insulation material.
  • Filler: Environmentally friendly flame-retardant rubber filler.
  • Inner Sheath: High-quality PVC inner sheath.
  • Armor: Double-layer steel tape armor structure.
  • Outer Sheath: Black PVC outer sheath.
YJV
YJV22
Name meaning
Y: Cross-linked polyethylene (XLPE) insulation
J: Copper conductor
V: Polyvinyl chloride (PVC) sheath
Y: Cross-linked polyethylene (XLPE) insulation
J: Copper conductor
V: Polyvinyl chloride (PVC) sheath
22: Double steel belt armor + PVC outer sheath
Armor
None
Steel tape armor
Mechanical protection
No armor, only PVC sheath
Double steel belt armor, compressive strength ≥400N/cm²
Installation method
Requires pipe/bridge protection
Can be directly buried or laid outdoors
Bending radius
≥12×cable diameter
≥20×cable diameter (harder armor)
Weight
Lighter (no metal layer)
30%~50% heavier than YJV
Application
Indoor, no risk of mechanical damage
Outdoor, buried, high corrosion environment

Key Advantages

  • High Voltage Adaptability: Meets the requirements of industrial high-voltage power transmission, exhibiting stable performance under rated voltage with no breakdown.
  • Wide Cross-Section Range: 10-300mm² cross-sections available.
  • Excellent Insulation Performance: XLPE insulation material features high insulation resistance, good heat resistance, and aging resistance.
  • Buried-Specific Design: Steel tape armor + double-layer sheath structure provides strong resistance to pressure, corrosion, and water.
  • Industrial-Grade Durability: The cable is abrasion-resistant, impact-resistant, rodent-resistant, and chemically resistant.
  • Standard Compliance: Passes rigorous quality testing to meet the import/export and industrial application requirements of various countries.
  • Long-Term Stable Operation: Compact structure and reliable performance enable long-term stable operation under complex conditions, reducing subsequent maintenance and replacement costs.

Application Scenarios

Based on its high-voltage performance and buried adaptability, this YJV22 High Voltage Cable is widely used in various industrial and infrastructure high-voltage power transmission scenarios, mainly including:
  • Underground power transmission and distribution of industrial plants (chemical plants, power plants, metallurgical plants, etc.)
  • High-voltage power supply lines for large-scale infrastructure projects (urban grid transformation, highway, railway, tunnel engineering)
  • Substation high-voltage connection and power distribution lines
  • Underground buried power transmission in industrial parks and industrial zones
  • High-voltage power supply for heavy industrial equipment and production lines
  • Outdoor and underground high-voltage power laying in harsh industrial environments (high humidity, corrosion, pressure)

YJV22 High Voltage Cable 10-300mm2 XLPE Insulated Buried Industrial Electrical Cable

FAQ (Frequently Asked Questions)

  • Q1: What is the difference between YJV22 High Voltage Cable and ordinary YJV22 cable? A1: The core difference lies in the voltage adaptation. This YJV22 High Voltage Cable is specially designed for high-voltage power transmission, with optimized insulation thickness and conductor structure, while ordinary YJV22 cable is mainly for low-voltage scenarios. In addition, this cable has a wider section range (10-300mm²) to meet the high current-carrying demand of high-voltage transmission.
  • Q2: Can the section size be customized outside 10-300mm²? A2: Yes, we support customized section size according to your specific industrial power transmission needs, and also provide customized core number and length.
  • Q3: Is this cable suitable for direct underground buried without additional protection? A3: Yes. The double steel tape armored structure and PVC double sheath make the cable have strong anti-compression, anti-corrosion and waterproof performance, which can be directly buried underground without additional protective pipes, saving construction time and cost.
  • Q4: What is the service life of this YJV22 High Voltage Cable? A4: Under normal industrial working conditions and standard laying, the service life can reach more than 30 years, with stable performance and low later maintenance cost.
  • Q5: Does it comply with international import standards? A5: Yes, the cable fully complies with GB/T and IEC international standards, passes strict quality testing, and can meet the import requirements of various countries and regions.
  • Q6: What is the packaging method of the cable?
  • A6: It is packed with high-quality wooden drum or steel-wood drum, with standard length of 100m/200m per drum. We can also customize the packaging and length according to your order requirements.
