AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna
Specifications
Brand Name :
AMEISON
Model Number :
AMXF-8027-8
Certification :
ISO 9001: 2008
Place of Origin :
China
MOQ :
100
Price :
EXW Price
Payment Terms :
TT,Paypal,Western Union
Supply Ability :
50,000 Pieces per Month
Delivery Time :
10-20 working days
Packaging Details :
PP bag /inner box/master carton or customized
Product name :
Omnidirectional Antenna
Frequency :
800-2700 mhz
Gain :
8dBi
VSWR :
≤1.5
Impedance :
50Ω
Polarization :
Vertical
connector type :
N Female
Dimensions :
Φ60*750
color :
White
Description

AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna

Feature :
Exquisite appearance
Good impact resistance,waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain,low standing wave,strong anti-interference ability


Application :
CDMA/GSM/PCS/2G/3G/4G/LTE/WIFI/WLAN system
Point-to-multipoint system

AMEISON Antenna Factory 806-960 / 1710-2700MHz 6/8 dBi outdoor Base Station 4g lte 800mhz repeater Omni antenna

698-2700MHz Omnidirectional Antenna

AMXF-8027-8

Electrical Specifications
Frequency range(MHz) 806-960 / 1710-2700
Bandwidth(MHz) 154/ 990
Gain(dBi) 6 / 8
Half-power beam width(°) H:360 V:25
V.S.W.R. ≤1.5
Input Impedance(Ω) 50
Polarization Vertical
Maximum input power(W) 100
Lightning protection DC Ground
Input connector type N female or Requested
Mechanical Specifications
Dimensions (mm) Φ60*750
Antenna weight(kg) 1.5
Operating temperature(°c) -40～60
Rated Wind Velocity(m/s) 60
Radome color White or others
Mounting way Wall/ Pole-holding
Waterproof Standard IP65/ IP67
Mounting hardware(mm) ￠35-￠50
