Specifications
MOQ :
1 piece
Display Mode :
STN
Controller :
ST7066U or AIP31066
Supply Ability :
5000000000 pieces/year
Product Name :
Custom Character LCD Display 4x16 16x4 LCD Module
Dimensions :
87.0mm * 66.0mm * 12.5mm
Operating Temperature :
-20°C to 70°C
Model Number :
WC1604B1
Display Type :
Character LCD Module
Backlight Color :
Usually Y-G or Blue or Gray
Interface :
16Pin, 4-bit or 8-bit 6800 MPU
Brand Name :
Formike
Display format :
16character*4 line
Operating Voltage :
3.3V / 5V
Payment Terms :
T/T,L/C,Credit card,Cash
Packaging Details :
Tray + Inner Box + Carton
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Backlight :
LED
Viewing Angle :
6 O'clock
Place of Origin :
China
Description

Custom Character LCD Display 4x16 16x4 LCD Module

Character 4x16 16x4 1604 LCD Display Module 6800 MPU Custom

Product Specification
LCD Name Custom Character LCD Display 4x16 16x4 LCD Module
Display Format 16character*4 line
Module Size 87.0mm×66.0mm×12.5mm
View Area 61.8mm×25.2mm
Character Size 2.95mm×4.75mm
Character Pitch 3.55mm×5.35mm
IC AIP31066 or Eqv (Defualt English / Japan Font)
Interface 16 Pin, 4-bit or 8-bit 6800 MPU interface enabled
Driving Method 1/16 Duty, 1/5 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WC1604B1SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WC1604B1SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WC1604B1SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WC1604B1SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WC1604B1SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WC1604B1SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
