Specifications
Display Type :
Character LCD
Viewing Angle :
6 O'clock
Controller :
ST7066U or AIP31066
Product Name :
16x4 LCD Display 1604a LCD Char Screen With Character Type
Place of Origin :
China
Operating Temperature :
-20°C to 70°C
MOQ :
1 piece
Backlight :
LED
Interface :
16 Pin, 4-bit or 8-bit 6800 MPU
Brand Name :
Formike
Packaging Details :
Tray + Inner Box + Carton
Model Number :
WC1604B0
Display format :
16character*4 line
Backlight Color :
Usually Y-G or Blue or Gray
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Dimensions :
87.0mm * 66.0mm * 12.5mm
Supply Ability :
5000000000 pieces/year
Display Mode :
STN
Payment Terms :
T/T,L/C,Credit card,Cash
Operating Voltage :
3.3V / 5V
Description

16x4 LCD Display 1604a LCD Char Screen With Character Type

5V 1604a 16x4 LCD Character Module Screen Display AIP31066 IC

Product Specification
LCD Name 16x4 LCD Display 1604a LCD Char Screen With Character Type
Display Format 16character*4 line
Module Size 87.0mm×66.0mm×12.5mm
View Area 61.8mm×25.2mm
Character Size 2.95mm×4.75mm
Character Pitch 3.55mm×5.35mm
IC AIP31066 or Eqv (Defualt English / Japan Font)
Interface 16 Pin, 4-bit or 8-bit 6800 MPU interface enabled
Driving Method 1/16 Duty, 1/5 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WC1604B0SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WC1604B0SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WC1604B0SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WC1604B0SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WC1604B0SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WC1604B0SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
