Specifications
Viewing Angle :
6 O'clock
Display Type :
Graphic LCD Display
Product Name :
19264 Graphic LCD Dot Matrix STN COB 192x64 LCD Screen
Display Mode :
STN
Operating Voltage :
3.3V / 5V
Place of Origin :
China
Dimensions :
100mm * 60mm * 12mm
Backlight :
LED
Brand Name :
Formike
Model Number :
WG1906B0
Supply Ability :
5000000000 pieces/year
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Display Format :
192x64 Dots
Interface :
20 Pin, 8-bit MPU
Operating Temperature :
-20°C to 70°C
Backlight Color :
Usually Y-G or Blue or Gray
Payment Terms :
T/T,L/C,Credit card,Cash
Packaging Details :
Tray + Inner Box + Carton
MOQ :
1 piece
Controller :
KS0107 & KS0108
Description

19264 Graphic LCD Dot Matrix STN COB 192x64 LCD Screen

19264 Graphic 192x64 LCD Dot Matrix STN COB Screen KS0107 & KS0108 Controller

Product Specification
LCD Name 19264 Graphic LCD Dot Matrix STN COB 192x64 LCD Screen
Display Format

192*64 Dots
Module Size 100.0mm×60.0mm×12.0mm
View Area 84.0mm×31.0mm
Active Area 78.68mmx26.20mm
Dot Size 0.37mm×0.37mm
Dot Pitch 0.41mm×0.41mm
IC KS0107 & KS0108
Interface 20 Pin, 8-bit MPU interface enabled
Driving Method 1/64 Duty, 1/9 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WG1906B0SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WG1906B0SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WG1906B0SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WG1906B0SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WG1906B0SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WG1906B0SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
