Specifications
Backlight :
LED
Backlight Color :
Usually Y-G or Blue or Gray
Payment Terms :
T/T,L/C,Credit card,Cash
Product Name :
192x64 LCD Display LCD19264 STN LCD Module Interface LCM
Model Number :
WG1906B1
Controller :
SBN0064G
Interface :
21 Pin, 8-bit MPU
Display Format :
192*64 Dots
Display Type :
Graphic LCD Screen
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Supply Ability :
5000000000 pieces/year
Dimensions :
120.0mm * 62.0mm * 13.5mm
Viewing Angle :
6 O'clock
Display Mode :
STN
Operating Temperature :
-20°C to 70°C
Place of Origin :
China
Packaging Details :
Tray + Inner Box + Carton
MOQ :
1 piece
Operating Voltage :
3.3V / 5V
Brand Name :
Formike
Description

192x64 LCD Display LCD19264 STN LCD Module Interface LCM

SBN0064G STN 192x64 LCD19264 LCD TFT Graphic Display Module Interface LCM

Product Specification
LCD Name 192x64 LCD Display LCD19264 STN LCD Module Interface LCM
Display Format

192*64 Dots
Module Size 120.0mm×62.0mm×13.5mm
View Area 104.0mm×39.0mm
Active Area 97.49mmx32.46mm
Dot Size 0.458mm×0.458mm
Dot Pitch 0.508mm×0.508mm
IC SBN0064G
Interface 21 Pin, 8-bit MPU interface enabled
Driving Method 1/64 Duty, 1/9 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WG1906B1SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WG1906B1SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WG1906B1SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WG1906B1SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WG1906B1SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WG1906B1SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
