Specifications
Payment Terms :
T/T,L/C,Credit card,Cash
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Dimensions :
133.00mm x 197.60mm x 4.61mm
MOQ :
1 piece
Product Name :
8 Inch TFT Display 800x1280 WXGA LCD Screen IPS MIPI Panel With Capacitive Touch
Viewing Angle :
All
Interface :
31 Pin, 4 LANE MIPI
Resolution :
800 x 1280
Display Size :
8 inch
Brand Name :
Formike
Place of Origin :
China
Supply Voltage :
3.3V
Operating Temperature :
-10°C to 60°C
Display Type :
8 Inch IPS TFT LCD Display
Touch Screen :
With capacitive touch panel
Supply Ability :
5000000000 pieces/year
Packaging Details :
Partition + A/S Bag + Corrugated Bar + Carton
Model Number :
KWH080KQ16-C01
Color :
Color
Description

8 Inch TFT Display 800x1280 WXGA LCD Screen IPS MIPI Panel With Capacitive Touch

800x1280 WXGA Screen TFT LCD IPS Display MIPI Panel With Capacitive Touch 8 Inch

Product Name 8 Inch TFT Display 800x1280 WXGA LCD Screen IPS MIPI Panel With Capacitive Touch
LCD Size 8 Inch IPS TFT LCD Display Module
Display Mode Transmissive
Resolution 800x1280
Outline Dimension (mm) 133.00x197.60x4.61
Active Area (mm) 107.64x172.22
Dot pitch (mm) 0.13455x0.13455
Viewing Direction All
Interface MIPI Interface, 31 Pin
Contrast Ratio 1200:1
Backlight 24 White LED

Backlight Supply

(Current/Voltage)

 60mA 22.4V~25.6V
Touch Screen With Capacitive Touch Panel

* KWH080KQ16-C01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 800x1280 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
