Transmissive RGB MCU 3.2 Inch TFT LCD Touch Screen 240x320 Display SPI Module

Specifications

Supply Ability :

5000000000 pieces/year

Viewing Angle :

12 O'Clock

Dimensions :

55.94mm x 77.60mm x 3.60mm

Product Name :

3.2 TFT LCD Touch Screen 240x320 Display RGB MCU Serial SPI LCD Module

Brand Name :

Formike

Supply Voltage :

3.2V

Display Type :

3.2 Inch TFT LCD Display

Display Size :

3.2inch

Resolution :

240 * 320

Place of Origin :

China

Payment Terms :

T/T, L/C, Credit card, Cash

Delivery Time :

In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;

Touch Screen :

Without (Optional with touch panel)

Packaging Details :

Tray + Inner Box + Carton

Model Number :

KWH032ST05-F02

Interface :

46 Pin, RGB, Serial and MCU Interface

Controller Ic :

ILI9341

Operating Temperature :

-20°C to 70°C

MOQ :

1 piece

Color :

Color

Description

3.2 TFT LCD Touch Screen 240x320 Display RGB MCU Serial SPI LCD Module

Product Name	3.2 TFT LCD Touch Screen 240x320 Display RGB MCU Serial SPI LCD Module
LCD Size	3.2 Inch TFT LCD Display Module
Display Mode	Transmissive
Resolution	240x320
Outline Dimension (mm)	55.94x77.60x3.60
Active Area (mm)	48.60x64.80
Dot Pitch (mm)	0.2025x0.2025
Viewing Direction	12 O'Clock
Interface	MCU/RGB/Serial Interface, 46 Pin
Driver IC	ILI9341
Brightness (Cd/m²)	260
Contrast Ratio	500:1
Backlight	5 White LED in Parallel
Backlight Supply (Current/Voltage)	75mA 3.2V
Touch Screen	With Resistive Touch Screen

Product Features

KWH032ST05-F02 is a Transmissive type color active matrix liquid crystal display (LCD)
Composed of a TFT LCD panel, driver IC, FPC, backlight, RTP
240x320 resolution TFT LCD module
Backlight with different brightness options from 250 - 1500cd/m² are available
Specific touch panel can be designed & customized
RoHS & REACH compliant
If you can't find a suitable one, contact us to get a recommendation
