KGD-YQ-510 Hand-held Infrared Methane Leak Imaging Large Storage Capacity 64G For Petrochemical Industry
KGD-YQ-510 Hand-held Infrared Methane Leak Imaging Large Storage Capacity 64G For Petrochemical Industry
Specifications
Brand Name :
KACISE
Model Number :
KGD-YQ-510
Certification :
CE
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Resolution :
320 x 256
Wavelength Range :
3.2 - 3.5μm
Temperature Measurement Range :
-20 - 350°C
Temperature Measurement Accuracy :
±1°C (0 - 100°C), ±2% (>100°C), ±2°C (-20 - 0°C)
Storage Method :
Standard SD card, 64G
Interface :
USB, HDMI, SD card, Wi - Fi
Description

KGD - YQ - 510 Hand - held Infrared Methane Leak Imaging for Petrochemical Industry

Product Introduction

The KGD - YQ - 510 Hand - held Methane Leak Infrared Imaging is a non - contact gas leak detector. It conducts infrared monitoring of inaccessible and leak - prone points in high - risk scenarios, quickly discovers methane leak points in the form of images, and accurately locates the leak positions or emission source positions. This helps inspectors quickly detect and promptly take remedial measures from a safe distance, ensuring the safety of operators while greatly avoiding losses caused by leaks. The system adopts Optical Gas Imaging (OGI) technology, with an explosion - proof rating of Ex ic nc op is IIC T4 Gc and a protection rating of IP54. It has reliable performance and is suitable for applications in petrochemical plants, refineries, well sites, oil and gas gathering and transportation areas, gas stations, natural gas pipelines, offshore oil platforms, Leak Detection and Repair (LDAR), environmental protection supervision and law - enforcement departments, and other fields.

KGD-YQ-510 Hand-held Infrared Methane Leak Imaging Large Storage Capacity 64G For Petrochemical Industry

Product Features

  • Gas visualization achieved by OGI technology.
  • Rapidly locates methane leak points in real - time.
  • Strong adaptability, clear imaging under low - light conditions.
  • Long - distance non - contact measurement.

Technical Parameters

Parameter Details
Resolution 320 x 256
Wavelength Range 3.2 - 3.5μm
Temperature Measurement Range -20 - 350°C
Temperature Measurement Accuracy ±1°C (0 - 100°C), ±2% (>100°C), ±2°C (-20 - 0°C)
Storage Method Standard SD card, 64G
Interface USB, HDMI, SD card, Wi - Fi
