Ultraviolet Hydrogen Sulfide Analyzer with 0 - 25000ppm Measurement Range, ±2%F.S. Accuracy, and Corrosion Resistant Materials
Ultraviolet Hydrogen Sulfide Analyzer with 0 - 25000ppm Measurement Range, ±2%F.S. Accuracy, and Corrosion Resistant Materials
Specifications
Brand Name :
KACISE
Model Number :
KGD-MQ-517
Certification :
CE
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Measured Component :
H₂S
Measurement Range :
0 - 25000ppm; Measurement range is selectable
Accuracy :
±2%F.S.
Resolution :
1ppm
Repeatability :
<2%
Response Time :
T90 < 30s
Description
KGD - MQ - 517 Ultraviolet Hydrogen Sulfide Analyzer
Product Overview

The KGD - MQ - 517 Ultraviolet Hydrogen Sulfide Analyzer is a new-generation hydrogen sulfide analyzer independently developed based on ultraviolet absorption spectroscopy gas analysis technology. It features a unique algorithm and high-precision gas cell, offering strong anti-interference capability and high measurement accuracy.

Ultraviolet Hydrogen Sulfide Analyzer with 0 - 25000ppm Measurement Range, ±2%F.S. Accuracy, and Corrosion Resistant Materials
Key Features
  • High accuracy: Utilizes ultraviolet absorption spectroscopy for real-time online monitoring with reduced gas cross-interference
  • Customizable measurement range: Can be tailored according to customer requirements
  • Strong corrosion resistance: All sample gas contact parts are manufactured from corrosion-resistant materials
  • Automatic zero-adjustment: Built-in air pump enables automatic air zero-adjustment
  • Multiple interface options: Data transmission to centralized control systems through various interfaces
  • Superior technology: Replaces electrochemical analysis and gas chromatographs with long service life, high cost-performance ratio, and low maintenance costs
Technical Specifications
Measured Component H₂S
Measurement Range 0 - 25000ppm (selectable range)
Accuracy ±2% F.S.
Resolution 1ppm
Repeatability <2%
Response Time T90 < 30s
Optimal Flow Rate (0.7 - 1.2) L/min
Inlet Pressure (2 - 50) kPa
Gas Requirements Dust-free, water-free, oil-free
Operating Temperature (5 - 35)℃
Communication RS-485/RS-232, (4-20)mA
Power Supply 220V ± 22V, 50Hz ± 1Hz
Display LCD Display
Alarm Output Passive contact signal
Functional Configuration Self-diagnosis function for online sensor status inspection
