PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping
Specifications
Brand Name :
ruiting
Model Number :
RTY-350G
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 days
Delivery Time :
20 working days
Packaging Details :
wooden case
Warranty :
1 Year
Voltage :
380V 3 phase
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas
Computerized :
Yes
Dimension(l*w*h) :
3.4(L)×1.6(W)×1.6(H)(m)
Type :
flatbed label die cutting machine
Weight :
About 450kg
Power(w) :
13kw
Max unwinding diameter :
800mm
Description

Title

Plastic PVC Film automatic flatbed label die cutting machine with hot stamping

Product Description

This die cutting machine is flat bedstructure, computer-servo system pull material. Feeding-die cutting-waste discharge-rewinding
sheet cutting, all processes are completed by computer in one time.

Main features

1.Adopt English Trio system,motion controller,intelligent servo PLC system.
2.Automatic web-guiding system
3.24000 times/h, 7200m/h die cutting, ensure run fast, high accuracy, working stably
4.use wood die cutter,cheap and durable.
5.Roller automatic inflate, driving system with automatic lubricate system,
Automatic tension control
6.It can do vertical and horizontal hot stamping
7.All are imported parts, such as electronic parts, bearing,transducer

Main Technical Specification:

Model
RTY-350G
cut speed
400 time/min
Max unwinding diameter
350mm
Max web width
350mm
Max die-cut Length
70m/min
Position accuracy
±0.1mm
Total power
13kw
Power voltage
380V, 3 phase (can make as your request)
Machine weight
About450kg
Overall dimension
2.6(L)×1.6(W)×1.6(H)(m)

Material details:

material
paper label, foam tape, PVC label
cutting mould
made by wooden

PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping

PVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot StampingPVC Film Flatbed Die Cutting Machines 380V 3 Phase With Hot Stamping

FQA

1.Are you factory or trading company?


We are factory.


2.What is your after service?


We offer customer a lifetime service.


3.Do you have CE certificate?

Yes, we have CE certificate of our machines.

4.What is the shipping time?


Around 15-30 days, depend on different model.


5.What can I do if machine stop work?
You can email us, call us or online video calls, face to face solve problem.
If the spare parts or something broken, in the warranty time,
we offer free.
