Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Flexible packaging High Speed Flexo Printing Machine 2 Color 420mm
Specifications
Brand Name :
ruiting
Model Number :
RYIN420-2
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
25 sets/month
Delivery Time :
in 30 days after receiving the deposit
Packaging Details :
Wooden Case
Usage :
horizontal flexo printer
Dimensions(l*w*h) :
2500*1000*1200mm
Voltage :
380V,3phase,50HZ
Warranty :
1 Year
Name :
2 Color 420mm Flexible packaging high speed flexo printing press
Printing Color :
2 color
Application :
Kraft paper, thermal paper,adhesive label paper,pvc film,aluminium foil
Max. material width :
420mm
Printing speed :
10-150m/min
Weight :
1800KGS
Description

2 Color 420mm Flexible packaging high speed flexo printing press

Main features

  • Ceramic anilox cylinder to transfer the ink
  • Automatic magnetic powder brake controller for unwinding & rewinding
  • Tension controller for unwinding
  • Tension controller for rewinding
  • Printing unit: 360°Plate-adjustment
  • IR dryer each printing unit
  • Web guide system in the machine
  • 3 inch air shaft both unwinding and rewinding
  • Frequency converter for speed controlling
  • 2 plate cylinders and 2 ceramic anilox rollers

Main technical specification:

Model RTIN-320-2
Printing speed 150m/minute
Printing color number 2 color
Max width of paper 420mm
Max printing wide 420mm
Max unwinding diameter 600mm
Max rewinding diameter 600mm
Printing length 175-635mm
Precision of overprint ±0.1mm
Overall dimension 2.5(L)×1.0(W)×1.2(H)m
Weight about 1800kg

Optional parts:(can add as your request)

  • Printing unit number, up to 10 colors;
  • turn bar device;
  • Slitting set
  • Video monitor
  • Rotary die cutting set
  • Cold laminating

Material details:

Printing material paper,foil, PVC,
Printing ink UV ink,water based ink
Printing plate thcikness 1.7mm
