Specifications
Brand Name :
ruiting
Model Number :
RTRY-320-1
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets/month
Delivery Time :
20 working days
Packaging Details :
wooden case
Usage :
Paper Printer
Automatic grade :
Automatic
Voltage :
220/380v
Weight :
750kgs
Warranty :
1 Year
Ink type :
water based ink,uv ink
Product name :
1 Color 320mm Flexo Printing Press With Rotary Die Cut Sheeting
Application :
all materials direct printing
Description

1 Color 320mm Flexo Printing Press With Rotary Die Cut Sheeting

Material details:

Printing material paper,foil, PVC,
Printing ink water based ink/UV ink
Printing plate thcikness 1.7mm

Optional parts:(can add as your request)

  • Printing unit number, up to 8 colors;
  • turn bar device;
  • Slitting set
  • Video monitor
  • Rotary die cutting set

Description:

  • Ceramic anilox cylinder to transfer the ink
  • Automatic magnetic powder brake controller for unwinding & rewinding
  • Tension controller for unwinding
  • Tension controller for rewinding
  • Printing unit: 360°Plate-adjustment
  • Both UV dryer and IR dryer in the machine
  • With cold foil set
  • The ink rollers will be separated from the printing roller, and keep running, when machine stopped.
  • Frequency inverter for speed controlling
  • Feed paper form roll material, print, coating, dry automatically by infrared ray and rewinding completed in one time.
  • It is an ideal machine for printing trade invoice and top-grade adhesive label paper, foil, PVC and so on material.

Main technical specification:

Model RTRY-320
Printing speed 10-60m/minute
Printing color number 1 color
Max width of paper 320mm
Max printing wide 310mm
Max unwinding diameter 500mm
Max rewinding diameter 500mm
Printing length 175-320mm
Thickness of flexo plate 1.7mm
Precision of overprint ±0.1mm
Overall dimension 2.0(L)×1.1(W)×1.3(H)m
Weight about 1200kg

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine

220/380v Narrow Web Flexo Printing Machine , 320mm Printing Press Cutting Machine
