210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
210mm Five Color Flexo Digital Printing Machine For Paper Roll
Specifications
Brand Name :
ruiting
Model Number :
RYIN210-5
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
25 sets/month
Delivery Time :
in 30 days after receiving the deposit
Packaging Details :
Wooden Case
Usage :
flexo printer
Dimensions(l*w*h) :
3900*1300*1500mm
Voltage :
380V,3phase,50HZ
Warranty :
1 Year
Name :
210mm Five Color Paper Roll Flexographic Label Printing Machine
Printing Color :
5 color
Application :
coated paper,pvc film,aluminium foil
Max. material width :
210mm
Printing speed :
120m/min
Weight :
2500kg
Description

210mm Five Color Paper Roll Flexographic Label Printing Machine

Main features

(1)Printing girth 190.5-635mm, filling the blank of the stack type flexo printing machine, trademark printng machine can not print long length

(2)Magnetic powder brake controller for unwinding & rewinding

(3)Printing unit: 360°Plate-adjustment

(4)IR dryer for each printing unit.

(5)With web guide system

(6)Use water based in( UV ink) , which max. Speed can be 90m/min

(7)The ink rollers will be separated from the printing roller, and keep running, when machine stopped.

(8)Frequency converter for speed controlling

(9)Feed paper form roll material, print,wen guide, dry automatically by infrared ray and rewinding completed in one time.

(10)It is an ideal machine for printing trade invoice and top-grade adhesive label.

Main technical specification:

Model RTIN-210
Printing speed 120m/minute
Printing color number 5 color
Max width of paper 210mm
Max printing wide 210mm
Max unwinding diameter 600mm
Max rewinding diameter 600mm
Printing length 175-635mm
Precision of overprint ±0.1mm
Overall dimension 3.9(L)×1.3(W)×1.5(H)m
Weight about 2500kg

Optional parts:(can add as your request)

  • Printing unit number, up to 10 colors;
  • UV system
  • turn bar device;
  • Slitting set
  • Video monitor
  • Rotary die cutting set
  • Cold laminating

Material details:

Printing material plastic,paper,foil, PVC,
Printing ink UV ink
Printing plate thcikness 1.7mm

210mm Five Color Flexo Digital Printing Machine For Paper Roll

210mm Five Color Flexo Digital Printing Machine For Paper Roll

210mm Five Color Flexo Digital Printing Machine For Paper Roll210mm Five Color Flexo Digital Printing Machine For Paper Roll

210mm Five Color Flexo Digital Printing Machine For Paper Roll210mm Five Color Flexo Digital Printing Machine For Paper Roll210mm Five Color Flexo Digital Printing Machine For Paper Roll

210mm Five Color Flexo Digital Printing Machine For Paper Roll
