Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Single Ball Type Air Quick Release Valve With Stainless Steel Yoke
Specifications
Brand Name :
TEYI
Model Number :
ARVX
Certification :
CE/API/ISO/TS
Place of Origin :
China
MOQ :
1-10PCS
Price :
negotiation
Payment Terms :
L/C at sight, T/T, Westem Union
Supply Ability :
5000PCS per month
Packaging Details :
Packed in carton firstly, and then reinforced with wooden case for outer packing
Product Name :
Single Ball Air Release Valve
Material :
Cast Iron
Size :
DN15 to DN50
Pressure :
PN6 to PN16
Connect End :
BSPT/BSP
Medium :
Water, Oil. Gas, Steam
Working Temp. :
0 to 180 ℃
Inspection Standard :
API 598
Description

Single Ball Type Air Quick Release Valve With Stainless Steel Yoke

Products Description

Air Release Valves function to release air pockets that collect at each high point of all pressured pipeline. Air Release VAlves can open against internal pressure, because the internal lever mechanism multiplies the float force to be greater than the internal pressure. This greater force opens the orifice whenever air pockets collect in the valve. Air Release Valves are essential for pipeline efficiency and water hammer protection.

Main part material

No. Name Material
1 Body Cast Iron
2 Bonnet Cast Iron
3 Ball Stainless Steel
4 Yoke Stainless Steel
5 Yoke Brass


Single Ball Type Air Quick Release Valve With Stainless Steel Yoke

Main Dimensions(mm)

Size G Outside Air relief size Ball H
DN15 1/2" 1/4" 1.6 125 127
DN20 3/4" 1/4" 1.6 125 127
DN25 1" 1/4" 1.6 125 127
