15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
15mm Longitudinal Finned Copper Pipe Embedded Fin Tube SS304 Stainless Steel ASTM A213
Specifications
Brand Name :
Yuhong
Model Number :
TP304,TP316L
Certification :
DNV, BV, PED, LR, ABS, TS, CCS
Place of Origin :
China
MOQ :
1 pc
Price :
Negotiable
Payment Terms :
L/C, T/T
Delivery Time :
7-45DAYS
Packaging Details :
Ply-wooden Case /Iron Case/ Bundle with plastic Cap
Base Tube Material :
TP304, TP316L,
Fin Material :
SS304, SS316L,
Fin Thickness :
1.23mm
Fin Connection :
Welding
Fin Height :
15.875mm
Application :
Furnace, Oil and Gas
Description
TP316L ASTM A213 Longitudinal Finned Pipe With SS316L Fins For Oil Cooler
Base Tube Material TP304, TP316L
Fin Material SS304, SS316L
Fin Thickness 1.23mm
Fin Connection Welding
Fin Height 15.875mm
Application Furnace, Oil and Gas
Longitudinal Finned Tube ASTM A213 TP316L Tube with SS316L Fins for Oil Cooler
Key Features
  • Base Tube Material: ASTM A213 TP316L Stainless Steel, providing excellent corrosion resistance, particularly in harsh environments like oil coolers where resistance to high temperatures and chemical exposure is crucial.
  • Fin Material: SS316L Stainless Steel, known for its exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, ideal for applications in oil coolers.
  • Fin Type: Longitudinal Fins, designed to provide efficient heat transfer by increasing the heat exchange surface area along the tube.
  • Application: Specifically engineered for oil cooler systems, providing high-performance cooling in hydraulic, mechanical, and industrial oil circuits.
Technical Specifications
Property Base Tube (ASTM A213 TP316L) Fin Material (SS316L)
Outer Diameter (OD) 15.88 mm - 50.8 mm Customizable based on design
Wall Thickness 1.5 mm - 4.0 mm -
Fin Thickness - 1.5 mm - 3.5 mm
Fin Height - 10 mm - 40 mm
Fin Attachment Welded or Mechanically Bonded
Chemical Composition
Element ASTM A213 TP316L (Base Tube) SS316L (Fin Material)
Carbon (C) ≤ 0.03% ≤ 0.03%
Manganese (Mn) 2.00% (max) 2.00% (max)
Phosphorus (P) ≤ 0.045% ≤ 0.045%
Sulfur (S) ≤ 0.030% ≤ 0.030%
Chromium (Cr) 16.00 - 18.00% 16.00 - 18.00%
Nickel (Ni) 10.00 - 14.00% 10.00 - 14.00%
Molybdenum (Mo) 2.00 - 3.00% 2.00 - 3.00%
Mechanical Properties
Property ASTM A213 TP316L (Base Tube) SS316L (Fin Material)
Tensile Strength ≥ 485 MPa ≥ 485 MPa
Yield Strength ≥ 170 MPa ≥ 170 MPa
Elongation ≥ 35% ≥ 35%
Advantages
  • Corrosion Resistance: SS316L fins and ASTM A213 TP316L base tube offer exceptional resistance to aggressive environments, including oils, chemicals, and saline conditions.
  • Efficient Heat Transfer: Longitudinal fins increase the surface area for heat exchange, making these tubes highly efficient in oil cooler applications.
  • High-Temperature Durability: Both materials maintain their mechanical properties even at elevated temperatures, ideal for oil cooling systems.
  • Enhanced Mechanical Stability: The welded or mechanically bonded fins ensure robustness under high pressures and thermal stress.
Applications
  • Oil Coolers: Effective in cooling oils in automotive, industrial, and marine systems.
  • Hydraulic Systems: Maintaining oil temperature in hydraulic machines and circuits.
  • Power Plants: For cooling lubricants and oils in machinery and compressors.
  • Chemical Processing: Oil cooling in equipment exposed to corrosive environments.
