SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module
SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module
SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module
SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module
Specifications
Brand Name :
YINGDA
Certification :
ISO,CE
Place of Origin :
China
MOQ :
10pcs
Price :
3.6usd-19.9usd
Payment Terms :
D/A,D/P,T/T
Delivery Time :
5-7 working days
Description

SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module


10G BIDI single fiber bidirectional SFP+ series optical transceiver support a variety of transmission distances from 10Km to 80Km. The series of products use a single LC optical interface, with low power consumption, small size, high reliability, wide temperature range and other characteristics. It is mainly used in SDH/SONET transmission environment.



Features:

  • Miniature Pluggable Transceiver designed for high performance
  • SFP Transceiver Module compatible with a wide range of network devices
  • Small Form-factor Pluggable design for easy installation and replacement
  • Supports high-speed data transmission with low power consumption
  • Hot-pluggable interface for seamless integration into existing systems
  • Reliable and durable construction for long-term use
  • Compliant with industry standards to ensure broad compatibilityOptical Parameters


Parameter

Symbol

Min.

Typical

Max.

Unit

Note

Transmitter Section

Centre Wavelength

λc

1260

1270

1280

nm

YSP96-B7320

1320

1330

1340

nm

YSP96-B3720

Spectral Width(-20dB)

Δλ

1

nm

Side Mode Suppression Ratio

SMSR

30

dB

Average Optical Power (avg.)

Pout

-3

+3

dBm

1

Laser Off Power

Poff

-

-

-30

dBm

Extinction Ratio

ER

3.5

-

-

dB

2

Relative Intensity Noise

RIN

-

-

-128

dB/Hz

Optical Rise/Fall Time

tr / tf

-

50

ps

3

Optical Return Loss Tolerance

-

-

12

dB

Output Optical Eye

Compliant with IEEE802.3ae eye masks when filtered

2

Receiver Section

Receiver Center Wavelength

λc

1320

1330

1340

nm

YSP96-B7320

1260

1270

1280

nm

YSP96-B3720

Receiver Sensitivity in Average Power

Sen

-14.4

0.5

dBm

4

Los Assert

LOSA

-30

-

-

dBm

Los Dessert

LOSD

-

-

-16

dBm

Los Hysteresis

LOSH

0.5

-

5

dB

Overload

Pin-max

-

-

0.5

dBm

4

Receiver Reflectance

-

-

-12

dB

Receiver Power (damage)

-

-

1.5

dBm




Applications:


◈ 10GBASE-LR/LW Ethernet

◈ 10G Fibre Channel

◈ SONET OC-192/SDH STM-64






FAQ:

Q1: What brand is the SFP Module?

A1: The SFP Module is manufactured by YINGDA, a reputable brand known for quality networking products.

Q2: Does the SFP Module have any certifications?

A2: Yes, the SFP Module is certified with ISO and CE, ensuring it meets international quality and safety standards.

Q3: Where is the SFP Module made?

A3: The SFP Module is made in China.

Q4: What is the minimum order quantity for the SFP Module?

A4: The minimum order quantity is 10 pieces.

Q5: What are the payment terms available for purchasing the SFP Module?

A5: We accept payment via D/A, D/P, and T/T.

Q6: How long does it take to deliver the SFP Module?

A6: The delivery time is typically 5-7 working days.

Q7: What is the price range for the SFP Module?

A7: The price range for the SFP Module is from 3.6 USD to 19.9 USD, depending on the specific model and order quantity.


SFP 10G 20km LC/UPC BIDI SFP Module Transceiver Optical Fiber Module


Compatible Brand

We product are compatible with Cisco, 3COM, H3C, HP, aruba, Finisar, Alcatel-Lucent, Allied Telesis, Nortel, Juniper, Huawei,etc.
