12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-0144
Certification :
CE, SGS, UL, RohS
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
25055PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Connector 1 :
LC UPC
Connector 2 :
LC UPC
Cable OD :
3.0mm
Cable Color :
Aqua
Length :
10m
Insertion Loss :
0.35dB
Reflection Loss :
35dB
Wavelength :
850nm
Description

12 Cores Fiber Optic LC UPC to LC UPC Multimode OM3 Pre-connectorized Multiple Cable

Our offers a wide range of patch cords, designed and manufactured for demanding network applications. It comprises of multimode and singlemode. Both ends are terminated with a high performance hybrid or single type connector comprising of a SC, ST, FC, LC, MU, MTRJ, E2000, DIN connector in simplex and duplex.

Standards Compliance

1. Telcordia (formerly Bellcore) GR-326-CORE Generic requirements for Single mode optical connectors and Jumper assemblies.

2. IEC 874-1 Generic specification for fiber optic connectors and cables

3. ANSI/TIA-568-C.3, ISO/IEC 11801 2nd Ed., CENELEC EN 50173, UL94V-0

4. Cable flame resistant rate: OFNR or IEC60332-3 standard

Features


(1) 100% tested on optical performance (Insertion Loss Customer specified length & Return Loss);

(2) Standard colour is Yellow, Orange, Aqua or Purple, other colours available upon request;

(3) Cable outer jacket available in PVC, Low Smoke Zero Halogen (LSZH);

(4) PC, UPC, APC connectors type available;

(5) High concentricity 2.5mm ceramic ferrule for FC, ST, SC and 1.25mm ceramic ferrule for LC and MU;

(6) Available in G652D, G657A, OM1, OM2, OM3 and OM4;

(7) Position A/Position B markings;

(8) Available in 0.9mm, 1.6mm, 2.0mm, 3.0mm sizes.

Technical Parameter

CABLE YELLOW FANOUT SINGLE-MODE
Applicable standards

CEI/EN 60793

CEI/EN 60794-1
CONSTRUCTION PERFORMANCE
Pulling load resistance (N) 4-6 fo: 600 / 800 8 – 12 – 16 fo: 1.000 / 1.500 / 2000 18 - 48 fo: 2.000 / 2.500
Crush resistance (N/cm) Da 200 a 250
Static bending radius (mm) 10 times x outer diameter
Dynamic bending radius (mm) 20 times x outer diameter
Temperature (°C) -20 / +80
Installing temperature (°C) -10 / +60
Temperature (°C) -20 / +80
MATERIALS
Outer sheath LSZH (yellow RAL 1018)
External sheath of single fiber LSZH (yellow RAL 1018)
Secondary sheath of single fiber Nylon - SEMITIGHT
Strenght member Aramid yarns
FIBER
SM - 9/125 SMF-28e
CONSTRUCTION FEATURES
Number of fibers 12 24 48
Outer diameter (mm) 10.5mm 13.5mm 17.8
Weight (kg/km) 50 78 135
Single fiber external diameter (mm) 0.9 ±0,1
Connectors Standard of LC, ST, FC, SC etc.

12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple

Hangalaxy Factory Cable Assembly

12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple

Hangalaxy Exhibition Activities

12 Cores Pre Terminated Fiber Optic Cable LC UPC To LC UPC Multimode OM3 Multiple

Ordering Sample

CONNECTOR MATING IL Average Standard IL MAX Standard IL Average Premium IL MAX Premium RETURN LOSS
Multimode 0.15 dB 0.30 dB 0.08 dB 0.15dB NA
Singlemode 0.18dB 0.30dB 0.12dB 0.15dB >55/65dB

Packing Information

1PCS Each Individual Quality PE Bag

If you feel any more request about the fiber optic connectivity, please give us a email and a call for asking and we will try our best service for you.
