Specifications
Brand Name :
Optowix
Model Number :
MBL-1H-B32LR/MBL-1H-B23LR
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
ESD plastic case
Supply Ability :
100Kpcs
Delivery Time :
5-8 working days
Product Name :
10G Bi-directoinal SFP+ 10km module
Application :
Telecommunication
SpeedRate :
10G
TX :
10G 1270nm/1330nm DFB laser
RX :
10G PIN Receiver
Distrance :
10km
Warranty :
36 Months
Interface :
LC Bidi
Description

10G BIDI SFP+ T1270R1330 10km Optical Transceiver Module Industrial Temp Module

Features

■ Compliant to SFP+ MSA

■ RoHS Compliant

■ Operating data rate up to 11.3Gbps

■ Two types: A: 1270nm DFB Transmitter/ 1330nm Receiver

B: 1330nm DFB Transmitter/ 1270nm Receiver

■ Single +3.3V±5% power supply

■ LC single connector

■ Hot pluggable 20pin connector

■ Power Dissipation < 1.5W

■Optional 10/20/40/60 transmission distance on 9/125um SMF

■PIN for 10/20/40km, APD for 60km

■ Operating Case Temperature Standard: -40℃~+85℃

■ Digital Monitoring SFF-8472 Rev10 compliant

Applications

  • 10GBASE-LR/LW
  • 10G Ethernet
  • OBSAI rates 3.072 Gb/s, 6.144Gb/s
  • CPRI rates 2.4576 Gb/s, 4.9152Gb/s, 6.144Gb/s,9.8304 Gb/s

Standards

  • IEEE 802.3ae
  • SFF-8431 Rev 4
  • SFF-8472 Rev 10

Ordering Information

Part. No Specifications
Rate Tx Tx WL Po Rx Sen. Top Reach Other
Gb/s nm dBm dBm ℃ km
MBL-1H-B23LR 10 DFB 1270 -6~0.5 PIN -14.4 -40~85 10 RoHS
MBL-1H-B32LR 10 DFB 1330 -6~0.5 PIN -14.4 -40~85 10 RoHS
