10G SFP+ 1310nm 220m Optical Transceiver Module For 10Gbps Optical Systems
10G SFP+ 1310nm 220m Optical Transceiver Module For 10Gbps Optical Systems
10G SFP+ 1310nm 220m Optical Transceiver Module For 10Gbps Optical Systems
10G SFP+ 1310nm 220m Optical Transceiver Module For 10Gbps Optical Systems
Specifications
Brand Name :
Optowix
Model Number :
MF1H-13T5
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
T/T
Supply Ability :
10Kpcs
Delivery Time :
5~8 working days
Packaging Details :
ESD plastic case
Optowix PN :
Optowix PN
Product Name :
10G SFP+ 1310nm 220m mudule
SpeedRate :
10G
Distrance :
220m
Interface :
LC
Description

10G SFP+ 1310nm 220m Module Optical Transceiver Module

Features

· Supports up to 10.7Gbps bit rates

· Hot-pluggable SFP+ footprint

· 1310nm FP laser and PIN photodiode, Up to 220m for MMF transmission

· Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle

· Compatible with RoHS

· Single +3.3V power supply

· Real Time Digital Diagnostic Monitoring

· Operating case temperature:

Standard: -5 to +70°C

Applications

· 10Gbps Optical systems

· 10GBASE-LRM at 10.3125Gbps

· Other Optical links

Standards

· SFF-8472

· SFP+ MSA

Ordering information

Part Number Product Description
MF1H-13T5 SFP+, 10G, 1310nm, 220m , -5°C~+70°C,

Description

· The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 220m transmission distance with MMF. The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.

Absolute Maximum Ratings

Parameter Symbol Min Max Unit
Supply Voltage Vcc -0.5 4.5 V
Storage Temperature Ts -40 +85 °C
Operating Humidity - 5 85 %

Recommended Operating Conditions

Parameter Symbol Min Typical Max Unit
Operating Case Temperature Standard Tc 0 +70 °C
Extended -20 +80 °C
Industrial -40 +85 °C
Power Supply Voltage Vcc 3.135 3.30 3.465 V
Power Supply Current Icc 350 mA
Data Rate 1.0 10.3 10.7 Gbps
