Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
Specifications
Brand Name :
E-link
Model Number :
LNK-INS901-24V
Certification :
CE/FCC/Rohs
Place of Origin :
China
MOQ :
1 PCS
Price :
USD $45-55
Payment Terms :
T/T,L/C,Western Union,MoneyGram,D/A,D/P
Supply Ability :
2000 per Month
Delivery Time :
3-10 working days
Packaging Details :
Gigabit Ethernet PoE Splitter Standard export package
PoE Standard :
IEEE 802.3af/at/bt Power over Ethernet
Power Output :
40W 24VDC (Terminal Block)
Power Consumption :
45W Max
Dimensions (WxDxH) :
95 x 70 x 30 mm
Weight :
0.25Kg
PWR :
24VDC Power OUT
Description

Industrial 10/100/1000Mbps 802.3bt PoE+ +Splitter Output Voltage 24VDC

Industrial Gigabit PoE Splitter Overview


The LNK-INS901-24V Series is an industrial-grade Gigabit Power over Ethernet (PoE) splitter

that delivers both data (via RJ45) and 24V power (via screw terminals) to non-PoE devices.

This product is compatible with IEEE 802.3af/at/bt PoE switches, thus eliminating the need

for separate power wiring while maintaining full Gigabit speeds up to 100 metres.

This robust splitter is designed for tool-free, plug-and-play installation, ensuring seamless

integration with LNK-INJ-48-95W PoE injectors. It is ideally suited for use with IP cameras,

wireless access points, and industrial IoT devices in challenging environments.


Industrial Gigabit PoE Splitter Features

  • Separates power and data from a PoE input source

  • 1× RJ45 PoE port (Data & Power In) and 1× RJ45 port (Data Out)

  • 1× 24V DC output via 2-pin terminal block

  • Compliant with IEEE 802.3af/at/bt (PoE++) standards

  • Supports 10/100/1000Base-T Ethernet

  • Transmission distance up to 100 meters

  • Short-circuit protection for power output

  • IP40-rated rugged metal housing , fanless design for reliable operation

  • Supports DIN-rail and wall-mount installation

  • Equipped with LED indicators for PoE and diagnostics

  • Wide operating temperature range: -40°C to +80°C (-40°F to +176°F)

Industrial Gigabit PoE Splitter Technical Indexes

Ethernet

Standards:

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Fast Ethernet

IEEE 802.3ab 1000Base-T Gigabit Ethernet

IEEE 802.3af Power over Ethernet

IEEE 802.3at Power over Ethernet Plus

IEEE 802.3bt 4-pair Power over Ethernet

Processing Type:

Forward

Half-duplex, Full-duplex

Forward Filter Rate:

1,488,000pps (1000Mbps)

Cabling:

1000Base-T: Cat5 or above

Maximum Distance:

Cat5 UTP up to 100m

Interface:

“PoE (Power + Data)” Input Port: 1 x RJ-45 10/100/1000Base-T

“Data” Out Port: 1 x RJ-45 10/100/1000Base-T

DC Out Plug Connector: 1 removable 2-Pin terminal block

Power over Ethernet

PoE Standard:

IEEE 802.3af/at/bt Power over Ethernet

Number of devices that can be powered:

1 (24VDC)

(Vary on device’s power requirement; cannot be over 40 watts.)

Environmental

Operating Temperature:

-40°C to 80°C (-40°F to 176°F)

Storage Temperature:

-40°C to 85°C (-40°F to 185°F)

Relative Humidity:

5% to 95% non-condensing

MTBF:

>200,000hrs

Electrical and Mechanical

Power Output:

40W 24VDC (Terminal Block)

Power Consumption:

45W Max.

LED Indicators:

PWR:

24VDC Power OUT

POE:

PoE Power IN

Dimensions (WxDxH):

95 x 70 x 30 mm

Weight:

0.25Kg

Casing:

Aluminum Case

Mounting Options:

DIN-Rail / Wall-mount

Regulatory Approvals

ISO9001

FCC part 15, Class A

EN55022:2006+A1: 2007 Class A

Surge Protection:

RJ45: 1KV

Power: 500W

ESD: 4KV/8KV


Industrial Gigabit PoE Splitter Ordering Information

Model

Description

LNK-INS901-24V

Industrial IEEE802.3bt Gigabit PoE Splitter Output Voltage 24VDC, maximum output of 40W at 24VDC, Support DIN-Rail mounting and Wall mounting installation, -40 to 80°C operating temperature

Mounting Options

► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.

Industrial Gigabit PoE Splitter Dimension
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs

Industrial Gigabit PoE Splitter Application
Industrial 24V PoE Splitter Plug Play Installation for IP Cameras APs
After-Sales and Warranty Policy
It is composed of online customer service and telephone customer service,
providing product consultation, remote technical support, maintenance
and acceptance services.

Service Policy: Three-month replacement and three-year warranty.

Replacement: Within three months of purchasing a series of products, after testing the product failure
by technicians and man-made damage caused by non-natural disasters, the purchaser can directly
go to the purchasing point to replace the same type of products.Or a product of comparable performance.
If there is no trouble in product testing, the original sample will be returned.

Warranty: Man-made damage caused by non-natural disasters, our company's free warranty period is 1 year.


[The following circumstances do not fall within the scope of replacement and free maintenance]


1.Damage caused by operation and maintenance not in accordance with the instructions in the product manual.
2.Damage caused by human factors, such as inappropriate voltage input, water intake and breakage.
3.Damage to products caused by natural disasters, such as lightning, earthquakes, fires, etc.
3.Unauthorized alteration of the inherent settings or repair without the company's permission.
4.Products beyond the scope of free maintenance.
5.Damage caused by transportation, loading and unloading during repairs sent by customers.
6.The product bar code or model on the product warranty card does not conform to the product itself.
7.Failure or damage caused by other non-product problems such as design, technology, manufacturing and quality.
