OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
Specifications
Brand Name :
JQ\OEM
Model Number :
GJXH GJXCH
Certification :
CE/ISO9001
Place of Origin :
China
MOQ :
1kilometer
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
80000kilometers per month
Delivery Time :
2-5days
Packaging Details :
Wooden Drum
Material of Sheath :
LSZH
Jacket colors :
Black/White/Customized Color
Strength member :
Steel wire
fiber brand :
YOFC
Fiber Type :
G652D/G,657A
Key words :
FTTH Optical Fiber Cable
Package :
Carton/customized
Description

Products Description

Self-support indoor/outdoor drop cable FTTH fiber optic cable
Fiber Optic Drop Cable access to the use of dish-shaped optical cable (indoor wiring) is the optical communication unit (fiber) in
the center, placed on both sides of two parallel non-metallic reinforcement (FRP) or metal reinforcing member, and finally
extrusion black or color poly Vinyl chloride (PVC) or LSZH (LSZH, low smoke, halogen-free, flame retardant) jacket.

Characteristic:

Flex durable fiber to provide greater bandwidth and enhance network transmission characteristics.

Two parallel metallic strength member to protect the fiber and provide adequate tension and pressure

single metallic strength member makes optical cable having good tensile performance.

Optical cable has simple structure, light weight and strong practicability.

unique groove design, Easy peeled off and splice, simplify the installation and maintenance

Low smoke halogen-free flame-retardant sheath, pro-environment.

Structural Parameter

Model No. Count

quter diameter(mm)±0.2mm

Weight

(kg/km)

 Tension
(N)

Crush

(N/100mm)

 Bending Radius Static / dynamic
(mm)
GJYXCH-1Xn 1 3.1*1.9 9 300/600 1000/2200 10/20
GJYXCH-2Xn 2 3.1*1.9 9 300/600 1000/2200 10/20

Fiber parameter

Item Unit Specification
Fiber Type G.652D

Mode field diameter

 1310nm mm 9.2±0.4
1550nm mm 10.4±0.8
Cladding diameter mm 125.0±1
Cladding non-circularity % ≤1.0
Core/cladding concentricity error mm ≤0.5
Coating diameter mm 245±5
Coating non-Circularity % ≤6.0
Coating/cladding concentricity error mm ≤12.0
Cable cut-off wavelength nm ≤1260

Attenuation Coefficient

 1310nm dB/km ≤0.36
1550nm dB/km ≤0.22
Proof stress level kpsi ≥100

Packing

1/2/3/4km or customized length export carton

OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket

Application

• Indoor and outdoor wiring system

• FTTH, terminal system

• Indoor and outdoor shaft,building wiring

OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket

OEM G652D FTTH Fiber Optic Drop Cable GJXH GJXCH Black Jacket
