Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Specifications
Model Number :
16 cores Distribution Box
Type :
Fiber optic terminal box
Place of Origin :
Zhejiang, China
Brand Name :
customize
Use :
FTTX ODB NAP FTTH
Warranty Time :
3 year
Network :
4g
Product name :
16 cores Distribution Box
Application :
Wall Mount Distribution Use
Material :
Premium PC/ABS material
Dimension (mm) :
385(L)*245(W)*130(H)mm
Function :
Distribution Fiber System (FTTH)
Certification :
Ip68/Ios9001, RoHS, ISO9001
Weight :
2420G
Connector Capacity :
16 pcs SC or 32 pcs LC connectors
Maximum install tray Number :
1 Splice Tray
MOQ :
20 PCS
Packaging Details :
blister packing >carton box>outer carton box
Port :
Ningbo or Shanghai
Supply Ability :
400000 Piece/Pieces per Month
MOQ :
100 pieces
Price :
$6.80/pieces 100-499 pieces
Description
16 ports Outdoor Waterproof Wall Mountable FTTH Fiber Splitter & Cable Distribution Box

Unload or Preloaded with 1:16 PLC fiber splitter with SC/UPC, SC/APC fiber adapters

 * Free Waterproof type Fiber Distribution Box Sample
* Made of Premium Grade Flame Resistant Material
* Suitable to SC/UPC or SC/APC Fiber Adapters & Pigtails
* Reasonable Bending Radius for Fiber Protection
* Can be used with Waterproof Adapter for Fast Connection
* Allow outdoor cable splitting fusion
* IP68 Waterproof grade


Basic Information
16 ports Outdoor Waterproof Wall Mountable FTTH Fiber Splitter or Cable Distribution Box is designed for wall mounted or pole mountable.It has 4 splice trays for managing the fiber pigtails. The material is of PC/ABS alloy.
Specification
Suitable Adapters
SC LC Fiber Adapter
Material
Premium PC/ABS material
Weight
2420G
Available Cable
Outdoor or Indoor Cable
Outlet
16 Port
Installation way
Wall Mount
Dimensions
385(L)×245(W)×130(H)mm
Applications
Wall Mountable
Compatible Riser Cable Types
Yes
Connector Capacity
16pcs SC or 32pcs LC connectors
Connector Type
SC LC
Drop Cable Connection
Yes
Includes Splitters
No
Indoor Outdoor
Both Indoor / Outdoor Cable
Location
Wall or Pole Usually
Location of Use
Fiber to the building or FTTH
Lock Compatible
Screws
Number of Terminal Drops
2 Cables
Number of Trays
1 Splice Tray
Product Type
Wall fiber distribution
Solution for
Wall Mount Cabling
Splice Capacity
16 fibers
Splitter Capability
Yes
Trademark
Teleweaver or Customized
Lead Time
5 days for 100pcs, 10 days for 800pcs
MOQ
20pcs
Product Description
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Q: What items are included in this 16 ports Outdoor Waterproof Wall Mountable FTTH Fiber Splitter & Cable Distribution Box?
A: A main parts (cover and base), 8 screws, 1 pcs key and 16 pcs heat shrinkable sleeves

Main Products
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Mini Type PLC Splitter
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Cassette Type PLC Splitter
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Rack Mounted Type PLC Splitter
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Insertion Type PLC Splitter
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Tray AssemblyType PLC Splitter
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Other goods
Company Profile
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Company Profile
Ningbo Kehao Hanxing Photoelectric Technology Co., Ltd was founded in 2002, which has been focusing on the field of optical and electrical communications for 20 years.
As the founders, the couple Chen Bo and Reng Chunfei started their own business at the beginning and now the team has 500 members.
1.Factory Direct, Best Price
At the same price, we offer the highest quality products. 2.Delivery Time: 7-10 Days
The company has a large number of stable employees over ten years. To ensure that the delivery time can be guaranteed at any time.
3.High Quality:
IQC-PQC-FQC-OQC.100% qualified. 4.Satisfactory Service:
Special team responsible for after-sales service,Includes installation instructions and technical support.Response within 1
hour,solution within 8 hours, after -sale service
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Production Workshop
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Product packaging
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
Why Choose Us
Outdoor Waterproof Wall Mountable FTTH Fiber Splitter Cable Distribution Box 16 Ports
FAQ
Q1. Can I have a sample order for this product? A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable. Q2. What about the lead time? A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than Q3. Do you have any MOQ limit for sample order? A: Low MOQ, 1pc for sample checking is available Q4. How do you ship the goods and how long does it take to arrive? A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional. Q5. How to proceed an order for the product? A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production. Q6: Do you offer guarantee for the products? A: 30 Years' Guarantee for fiber optic PLC splitter 25 Years' Guarantee for fiber optic cable
